AOOSTAR MACO AMD R7 6850H Mini PC User Manual

1. Giriş

This manual provides detailed instructions for setting up, operating, and maintaining your AOOSTAR MACO AMD R7 6850H Mini PC. Please read this manual thoroughly before using the device to ensure proper functionality and to prevent damage.

The AOOSTAR MACO AMD R7 6850H Mini PC is a compact computing device designed for various tasks, including office productivity, content creation, and multimedia consumption. It features an AMD Ryzen 7 PRO 6850H processor, LPDDR5 RAM, and multiple connectivity options.

2. Kutuda Neler Var?

Upon unpacking, please verify that all items listed below are present and in good condition. If any items are missing or damaged, please contact customer support.

• 1x AOOSTAR MACO 6850H Mini PC
• 1x 120W Power Supply
• 1x HDMI Kablosu
• 1x SSD Cooling Pad
• 1x Montaj Vidası Seti
• 1x Kullanım Kılavuzu (bu belge)

The image above shows the main components included in the package. The mini PC is a compact silver unit, accompanied by its power adapter, an HDMI cable for display connection, and the user manual. Additional small accessories like an SSD cooling pad and mounting screws are also part of the package.

3. Ürün Bittiview

3.1 Ön Panel

• Power Button with Fingerprint Sensor: Press to power on/off. Supports Windows Hello for secure login.
• USB4 Port (x1): Yüksek hızlı veri aktarımı ve ekran çıktısı.
• USB 3.2 Gen2 Tip-A Bağlantı Noktaları (x2): USB cihazlarını bağlamak için.
• 3.5 mm Ses Jakı: Kulaklık veya harici hoparlörler için.

The front panel provides convenient access to essential ports. The power button also integrates a fingerprint sensor for enhanced security. Two USB 3.2 Type-A ports are available for peripherals, alongside a versatile USB4 port and a 3.5mm audio jack.

3.2 Arka Panel

• DC Giriş Bağlantı Noktası: Connect the 120W power adapter here.
• USB4 Port (x1): Additional high-speed data transfer and display output.
• 2.5G LAN Ports (x2): Kablolu ağ bağlantıları için.
• HDMI 2.1 Port (x1): Ekrana bağlanmak için.
• DisplayPort 1.4 (x1): Ekrana bağlanmak için.
• USB 2.0 Bağlantı Noktaları (x2): USB cihazlarını bağlamak için.
• Oculink Port (x1): Dedicated port for external GPU connection.

The rear panel offers extensive connectivity for power, networking, and multiple displays. It includes a DC IN port, a second USB4 port, dual 2.5G LAN ports for robust network connections, HDMI 2.1 and DisplayPort 1.4 for video output, two USB 2.0 ports, and a specialized Oculink port for external graphics solutions.

4. Kurulum Talimatları

4.1 İlk Bağlantı

1. Ekranı Bağla: Use the provided HDMI cable to connect your monitor to the HDMI port on the Mini PC. Alternatively, use the DisplayPort or USB4 ports for other display types.
2. Çevre Birimlerini Bağlayın: Plug in your keyboard and mouse to the available USB ports (USB 3.2 Type-A on the front or USB 2.0 on the rear).
3. Gücü bağlayın: Connect the 120W power adapter to the DC IN port on the rear of the Mini PC, then plug the adapter into a power outlet.
4. Güç Açık: Mini bilgisayarı açmak için ön paneldeki güç düğmesine basın.

This image illustrates a typical setup with the Mini PC connected to a display, keyboard, and mouse. Ensure all cables are securely connected before powering on the device.

4.2 Operating System Setup (Barebone Version)

If you purchased the barebone version without an SSD/OS, you will need to install an operating system. The device supports Windows 11 Pro. Contact customer service to request a free Windows 11 Pro key if applicable.

1. SSD'yi takın: Open the bottom cover (refer to Maintenance section for instructions) and install your M.2 2280 PCIe 4.0 x4 SSD into one of the three available slots.
2. Create Bootable USB: Prepare a bootable USB drive with your desired operating system (e.g., Windows 11 Pro installer).
3. Install OS: Insert the bootable USB drive, power on the Mini PC, and follow the on-screen instructions to install the operating system.

This image shows the internal layout of the Mini PC, specifically the M.2 slots where SSDs can be installed. The device supports up to 24TB of storage across these slots, with RAID 0/1/5 configurations possible.

5. Kullanım Talimatları

5.1 Temel İşlemler

• Güç Açma/Kapatma: Press the power button once to turn on. To turn off, either shut down via the operating system or press and hold the power button for 5 seconds.
• Fingerprint Login: For Windows Hello compatible systems, gently place your registered finger on the power button for quick and secure login.
• Quad-Screen Display: Connect up to four displays using the HDMI 2.1, DisplayPort 1.4, and two USB4 ports. This allows for extended desktop environments.

This image showcases the Mini PC's ability to drive four displays simultaneously, ideal for multitasking and professional workflows. The various display ports (HDMI, DisplayPort, USB4) offer flexibility in monitor connections.

5.2 Gelişmiş Özellik

• Oculink External GPU: The dedicated Oculink port allows for connecting an external GPU (eGPU) for enhanced graphics performance, suitable for gaming or demanding creative applications.
• RAID Yapılandırması: With three M.2 slots, you can configure RAID 0, 1, or 5 arrays for improved storage performance or data redundancy.
• Yüksek Hızlı Ağ Bağlantısı: Utilize the dual 2.5Gbps LAN ports for fast and stable wired network connections, or connect wirelessly via WiFi 6 and Bluetooth 5.2.

This image illustrates the Oculink port's function, allowing the Mini PC to connect to an external GPU for significantly boosted graphical capabilities, transforming it into a more powerful workstation or gaming machine.

6. Bakım

6.1 Temizlik

• Mini PC'nizin dışını düzenli olarak yumuşak ve kuru bir bezle temizleyin.
• Use compressed air to clear dust from the ventilation grilles to maintain optimal cooling performance.
• Temizlemeden önce cihazın kapalı ve fişinin çekilmiş olduğundan emin olun.

6.2 Depolama Genişletmesi

The Mini PC supports up to three M.2 2280 PCIe 4.0 x4 SSDs. To install or replace an SSD:

1. Power off the device and unplug all cables.
2. Carefully remove the four screws on the bottom plastic cover.
3. Gently pry open the bottom cover to access the M.2 slots.
4. Insert the M.2 SSD into an available slot and secure it with the provided mounting screw.
5. Attach the SSD cooling pad if desired.
6. Alt kapağı yerine takın ve vidaları sıkın.

Bu görüntü net bir görüntü sağlar view of the internal components, particularly the M.2 slots, which are accessible by removing the bottom cover. This is where users can install or upgrade their NVMe SSDs.

7. Sorun Giderme

8. Özellikler

9. Garanti ve Destek

AOOSTAR provides a 12-month worry-free warranty for the MACO AMD R7 6850H Mini PC. Additionally, lifetime technical support is available for all customers.

For any product-related issues, technical assistance, or warranty claims, please contact AOOSTAR customer service. If you encounter any problems with the product, please email us instead of mistakenly contacting the Amazon platform. As a sales platform, they do not understand product technical issues and cannot resolve the problems you are facing.

If you have the time or wish to get the most out of this product, it would be best to send us an email (including the purchase date and order number) when you have the time. We will register this internally, and our after-sales center can assist you more quickly when you encounter product issues in the future. Additionally, we can also offer an extended 6-month warranty period.

If you encounter a product issue that requires telephone or voice communication, please notify us via email first. We will arrange for a corresponding voice customer service representative to assist you. (As we sell in many countries, advance notice is required.)

İletişim E-postası: aoostar-shop@outlook.com
