giriiş
Thank you for choosing the KIBTOY Battery Operated Wall Sconces. These wireless wall lights are designed to provide versatile and convenient lighting for various spaces in your home. Featuring a 10,000mAh rechargeable battery, multiple color options including 9 RGB colors and 4 white light temperatures, and remote control functionality, these sconces offer an elegant lighting solution without the need for complex wiring.
This manual provides essential information for the safe and efficient use of your new wall sconces. Please read it thoroughly before installation and operation, and retain it for future reference.
Güvenlik Bilgileri
- Pil Güvenliği: Do not expose the battery to extreme temperatures, direct sunlight, or fire. Do not disassemble, puncture, or modify the battery. Use only the provided USB-C cable for charging.
- Kurulum: Ensure the mounting surface is clean, dry, and capable of supporting the weight of the sconce. Avoid installing near heat sources or in excessively humid environments.
- Temizlik: Disconnect the light bulb before cleaning. Use a soft, dry cloth. Do not use abrasive cleaners or solvents.
- Çocuklar: Keep the remote control and small parts out of reach of children to prevent choking hazards.
Paket İçeriği
Paketinizde tüm öğelerin mevcut olduğundan emin olun:
- Wall Sconce Unit (including lampshade, metal base, and rod)
- Rechargeable Magnetic LED Bulb (10,000mAh)
- Uzaktan kumanda
- USB-C Şarj Kablosu
- Mounting Hardware (screws, anchors, mounting bracket)
- Kullanıcı Kılavuzu
Kurulum ve Yükleme
The KIBTOY Wall Sconces are designed for easy, wireless installation, requiring no electrical wiring.
- Assemble the Sconce:
Image: An assembled KIBTOY wall sconce with its magnetic bulb and remote control shown separately.
- Tüm bileşenleri dikkatlice ambalajından çıkarın.
- l'yi ekleampshade to the sconce arm.
- Insert the magnetic LED bulb into the lampshade. The bulb will securely attach to the magnetic base.
- Mount the Sconce:
Image: A diagram illustrating the simple installation process, highlighting no need for complex wiring or electrical outlets.
- Choose a desired location on your wall.
- Use the provided mounting bracket as a template to mark the screw positions.
- Gerekirse pilot delikler açın ve duvar dübellerini yerleştirin.
- Montaj braketini vidaları kullanarak duvara sabitleyin.
- Attach the sconce's base to the mounted bracket.
Video: An official KIBTOY video demonstrating the installation steps for the wall sconce, including attaching the lampshade, inserting the magnetic bulb, and mounting the unit to the wall.
Kullanım Talimatları
Your KIBTOY Wall Sconce can be operated using the included remote control or the button on the magnetic bulb.
Uzaktan Kumanda Fonksiyonları:
Image: A visual guide to the remote control and the manual button on the bulb, detailing their respective functions.
- AÇIK/KAPALI: Press the green 'ON' button to turn on, red 'OFF' button to turn off.
- Parlaklık Ayarı: Use the sun icon buttons (up/down) to increase or decrease brightness. There are 4 brightness levels (15%, 50%, 75%, 100%).
- Renk Sıcaklığı: Select from 4 white light temperatures: 1800K (Warm Light), 3000K, 4000K, 6000K (Cold Light).
- RGB Renkler: Choose from 9 vibrant RGB colors using the dedicated color buttons.
- Zamanlayıcı Fonksiyonu: Set the light to automatically turn off after 30, 60, or 120 minutes using the timer buttons.
Image: The magnetic bulb highlighting its timing function, with options for 30, 60, and 120 minutes.
- Hafıza Fonksiyonu: The sconce automatically remembers your last color and brightness settings when powered off and on again.
Bulb Button Control:
- Tek tık: Işığı AÇIK/KAPALI konuma getirir.
- Çift tıklama: Switches between different light functions (e.g., color temperatures, RGB modes).
- Uzun basma: Activates stepless dimming for static colors.
Video: An official KIBTOY video demonstrating the remote control features, including brightness adjustment, color temperature changes, and cycling through 9 RGB colors.
Şarj Talimatları
The KIBTOY Wall Sconce features a 10,000mAh rechargeable magnetic bulb for extended use.
- Kolay Çıkarma: The magnetic bulb detaches easily from the sconce for convenient charging. No need to unscrew or remove the entire fixture.
- USB-C Şarjı: Connect the provided USB-C charging cable to the port on the bulb and to a compatible USB power adapter (not included).
- Şarj Süresi: Tam şarj genellikle 4-5 saat sürer.
- Pil Ömrü: Enjoy up to 24 hours of illumination on maximum brightness or up to 80 hours on the lowest setting.
Image: The sconce with its dimensions, and a close-up of the magnetic bulb being charged via its USB-C port.
Bakım
- Temizlik: To clean the sconce, gently wipe the surfaces with a soft, dry cloth. For the lampshade, a lint roller or soft brush can be used to remove dust. Ensure the bulb is removed or turned off before cleaning.
- Pil Bakım: For optimal battery longevity, avoid completely draining the battery frequently. Recharge the bulb when the light output noticeably diminishes.
- Depolamak: If storing the sconce for an extended period, ensure the battery is partially charged (around 50%) and store in a cool, dry place.
Sorun giderme
| Sorun | Olası Neden | Çözüm |
|---|---|---|
| Işık açılmıyor. | Pil bitmiş. | Charge the magnetic bulb using the USB-C cable. |
| Light is dim or flashing. | Pil zayıf. | Recharge the magnetic bulb. |
| Uzaktan kumanda çalışmıyor. | Remote battery is depleted or line of sight is blocked. | Replace the remote control battery. Ensure direct line of sight to the bulb. |
| Bulb not charging. | Kablo veya güç adaptörü arızalı. | Farklı bir USB-C kablosu veya güç adaptörü deneyin. Kablonun tam olarak takılı olduğundan emin olun. |
| Magnetic bulb detaches easily. | Improper seating or external force. | Ensure the bulb is properly seated on the magnetic base. Avoid bumping the sconce. |
Özellikler
- Marka: KİBTOY
- Model Numarası: 360-CX04
- Malzeme: Metal
- Işık Armatür Formu: Aplik
- Oda Tipi: Bedroom, Dining Room, Entryway, Living Room
- Işık Kaynağı Sayısı: 1
- Ürün Ağırlığı: 2.4 pound (1.09 Kilogram)
- Ürün Ölçüleri: 16.54 x 12.6 x 22.64 inç
- Pil: 10,000mAh Lityum İyon (dahil)
- Şarj: USB-C
- Renk Sıcaklıkları: 1800 bin, 3000 bin, 4000 bin, 6000 bin
- RGB Renkler: 9 seçenek
- Parlaklık: Up to 300 lumens, 4 levels dimmable
- Çalışma zamanı: 24-80 saat (parlaklığa bağlı olarak)
- Montaj Gerekli: No (minimal assembly for installation)
Garanti ve Destek
KIBTOY is committed to customer satisfaction. If you encounter any issues with your product, please contact our customer service team. We typically assist customers with the following:
- Defective item replacements.
- Lights flashing or turning off during use.
- Kayıp parçalar.
- Battery damage or charging problems.
- Installation guidance.
For support, please submit your order number to service01@kibtoy.com.
