iZEEKER Solar Trail Camera iG220 & 4G LTE Cellular Trail Camera iG500 User Manual

1. Giriş

This manual provides detailed instructions for the iZEEKER Solar Trail Camera iG220 and the iZEEKER 4G LTE Cellular Trail Camera iG500. This bundle offers advanced features for capturing wildlife and monitoring remote areas, combining solar power efficiency with cellular connectivity for comprehensive surveillance.

Figure 1: The iZEEKER iG220 Solar Trail Camera (left) and iG500 4G LTE Cellular Trail Camera (right) bundle, including a SIM card and 32GB SD card.

2. Paket İçeriği

iG220 Package:

• 1 x iG220 Trail Camera
• 1 x USB Kablosu
• 1 x Kullanım Kılavuzu
• 1 x Kayış

iG500 Package:

• 1 x iG500 Trail Camera
• 1 x SIM Card
• 1 x Mikro SD Kart
• 1 x Güneş Paneli
• 1 x Kullanım Kılavuzu
• 1 x USB Kablosu
• 1 x Outdoor Mount
• 1 x Konumlandırma Etiketi
• 1 x Montaj Braketi

3. Özellikler

iG220 Specifications:

iG500 Specifications:

Figure 2: The iG220 camera offers 36MP photo resolution and 1520P video resolution, providing clear images in both day and night conditions.

Figure 3: The iG500 camera provides a 360-degree panoramic view with 336-degree pan and 90-degree tilt functionality, allowing for extensive coverage.

4. Kurulum Kılavuzu

4.1 Pil Kurulumu

Both cameras are designed for efficient power usage. The iG220 uses standard AA batteries (not included), while the iG500 includes two Lithium Ion batteries. Ensure batteries are inserted with correct polarity.

Figure 4: Both iG220 and iG500 models can utilize solar power for extended battery life, reducing the need for frequent battery replacement.

4.2 SD Kart Takılması

Insert the provided Micro SD card (for iG500) or your own SD card (for iG220) into the designated slot. Ensure the card is formatted before first use for optimal performance. The iG220 supports continuous loop recording, overwriting old filekartın dolduğu zamandır.

4.3 SIM Card Installation (iG500 Only)

For the iG500 cellular trail camera, insert the provided SIM card into its slot. The camera is designed to auto-connect to cellular networks with strong signals (Verizon, T-Mobile, AT&T compatible).

Figure 5: The iG500 camera features 4G Auto Connect Technology, allowing it to automatically connect to cellular networks without requiring Wi-Fi.

4.4 Kamerayı Monte Etme

Use the provided strap (iG220) or outdoor mount and installation bracket (iG500) to secure the camera to a tree or pole. Position the camera to capture the desired area, considering the detection and lens angles.

Figure 6: The iG500 can be paired with its solar panel for continuous charging, extending battery life significantly.

5. Kullanım Talimatları

5.1 Powering On and Basic Modes

Turn on the camera using the power switch. Navigate through the menu on the LCD screen (iG220) or via the mobile app (iG500) to select desired modes: Photo, Video, or Photo+Video. Adjust settings such as resolution, trigger speed, and PIR sensitivity.

Figure 7: Both cameras feature a rapid 0.1-0.3 second trigger speed, ensuring minimal delay in capturing fast-moving subjects.

5.2 Night Vision Operation

Both cameras are equipped with 940nm no-glow infrared LEDs for discreet night vision. The iG500 also features 4 white LEDs for color images at night. Ensure the camera is positioned to avoid obstructions that might reflect IR light.

Figure 8: The 940nm no-glow infrared LEDs ensure the camera remains stealthy during night operation, preventing disturbance to wildlife.

Figure 9: The iG500 offers two night vision modes: a spotlight mode for color images and a no-glow infrared mode for discreet black and white capture.

5.3 Advanced Features (iG220)

• Zaman aralığı: Ardışık tetiklemeler arasındaki gecikmeyi ayarlayın.
• Zamanlayıcı: Schedule the camera to operate only during specific hours.
• Zaman Atlaması: Capture images at set intervals over a long period.
• Döngü Kaydı: En eskisinin üzerine otomatik olarak yaz files SD kart dolduğunda.
• PIR Hassasiyeti: Adjust the motion sensor's sensitivity to prevent false triggers.
• Şifre Koruması: Kamera ayarlarınızı bir şifreyle koruyun.

5.4 Advanced Features (iG500)

• Remote Access & Control: Use your smartphone to access and control the camera remotely.
• İki yönlü İnterkom: Communicate through the camera (if supported by app/firmware).
• Çoklu Kullanıcı Paylaşımı: Share camera access with multiple users.
• Alarm Zamanlayıcı: Set specific times for alerts.
• Depolama Yöntemi: Choose between SD card and cloud storage options.
• Yatay Kaydırma ve Eğme: Kameranın ayarlarını uzaktan yapın. viewing angle (336° pan, 90° tilt).

6. Bakım

• Temizlik: Regularly clean the camera lens and PIR sensor window with a soft, dry cloth. Avoid abrasive materials.
• Pil Kontrolü: Periodically check battery levels, especially if not using solar charging. Replace or recharge as needed.
• SD Kart Yönetimi: Format the SD card regularly to maintain optimal performance and prevent data corruption. Back up important filebiçimlendirmeden önce.
• Donanım Yazılımı Güncellemeleri: Check the iZEEKER website for any available firmware updates to ensure your camera has the latest features and bug fixes.
• Depolamak: When not in use, store the camera in a cool, dry place, away from direct sunlight and extreme temperatures. Remove batteries if storing for extended periods.

7. Sorun Giderme

Kamera Açılmıyor:

• Pillerin doğru kutuplara sahip olacak şekilde doğru şekilde takıldığından emin olun.
• Check battery charge level. Replace or recharge batteries.
• Güç anahtarının "AÇIK" konumunda olduğundan emin olun.

Düşük Görüntü/Video Kalitesi:

• Kamera lensini temizleyin.
• Kameranın sabit olduğundan ve titreşime maruz kalmadığından emin olun.
• Check resolution settings in the camera menu.
• For night vision, ensure no reflective surfaces are too close to the camera.

Hareket Algılama Yok:

• Adjust PIR sensitivity settings (increase if needed).
• Ensure the PIR sensor window is clean and unobstructed.
• Verify the camera is positioned within the detection angle.
• Check for environmental factors like extreme heat or cold that might affect sensor performance.

iG500 Cellular Connectivity Issues:

• SIM kartın doğru şekilde takıldığından ve bir veri planıyla etkinleştirildiğinden emin olun.
• Check cellular signal strength in the camera's location. Relocate if signal is weak.
• Kamerayı yeniden başlatın.
• Verify APN settings if manual configuration is required (refer to your cellular provider's instructions).

8. Garanti ve Destek

iZEEKER products come with a standard manufacturer's warranty. For specific warranty details, technical support, or service inquiries, please visit the official iZEEKER webSiteyi ziyaret edin veya doğrudan müşteri destekleriyle iletişime geçin. Garanti talepleri için satın alma fişinizi satın alma belgesi olarak saklayın.

You can visit the iZEEKER Store on Amazon for more information: iZEEKER Amazon Store
