Witt ETNA Rotante Pizza Fırını Kullanım Kılavuzu

1. Giriş

Welcome to the Witt ETNA Rotante Pizza Oven. This manual provides essential information for safe and efficient operation, setup, maintenance, and troubleshooting. Please read thoroughly before first use to ensure optimal performance and safety.

Figure 1: Witt ETNA Rotante Pizza Oven in Mat Orange.

2. Güvenlik Bilgileri

Güvenliğiniz bizim için çok önemlidir. Lütfen aşağıdaki kurallara uyun:

• Yalnızca Dış Mekan Kullanımı: Bu cihaz yalnızca dış mekan kullanımı için tasarlanmıştır. İç mekanlarda veya kapalı alanlarda çalıştırmayın.
• Havalandırma: Çalışma sırasında fırın çevresinde yeterli havalandırma olduğundan emin olun.
• Açıklıklar: Maintain a minimum clearance of 1 foot (30 cm) from the back and sides, and 3 feet 4 inches (1 meter) from the front and above, to any combustible materials.
• Kararlı Yüzey: Always place the oven on a secure, level, and non-combustible surface.
• Sıcak Yüzeyler: Surfaces become extremely hot during use. Do not touch hot parts without appropriate protective gear.
• Gaz Bağlantısı: Gas connection requirements may vary by country. Always ensure connections are secure and leak-free.
• Gaz sızıntısı: If you smell gas, immediately shut off the gas supply to the appliance and extinguish any open flames. Do not attempt to ignite the oven.
• Kaldırma: The oven is heavy. It must be lifted and moved by at least two people to prevent injury.

3. Ürün Bittiview

The Witt ETNA Rotante Pizza Oven is engineered for exceptional outdoor pizza making. Key features include:

• 360 Derece Dönen Pizza Taşı: Ensures perfectly even cooking and crispy crusts without manual turning.
• Dual Burner System: Features a U-shaped main burner and an additional booster burner located beneath the pizza stone for rapid heating and consistent high temperatures.
• Hızlı Pişirme: Capable of cooking pizzas in under 60 seconds once preheated.
• Dayanıklı Yapı: Made from high-quality alloy steel and aluminum for longevity.
• Geniş Pişirme Alanı: Accommodates pizzas up to 16 inches (40.5 cm) in diameter.
• Taşınabilirlik: Equipped with foldable aluminum legs with rubber bottoms for easy setup and storage.

Figure 2: Key features of the Witt ETNA Rotante Pizza Oven.

4. Kurulum

1. Paketin açılması: Carefully remove the oven and all components from the packaging. Retain packaging for future transport or storage.
2. Stone Placement: Ensure the 360-degree rotating pizza stone is correctly seated within the oven. If there is a visible gap at the front of the stone, use the included stone adjustment tool to hook the back of the stone and pull it forward until it is flush.
3. Konumlandırma: Place the oven on a stable, level, and non-combustible outdoor surface. Ensure all safety clearances mentioned in Section 2 are met. If using on a windy day, orient the oven so the mouth faces away from the wind.
4. Gaz Bağlantısı:
   • Pull the collar back on the gas hose connector and firmly attach the hose onto the gas inlet on the oven.
   • Attach the regulator to your propane gas tank. Ensure all connections are tight. (Note: Gas connection types may vary by country. Refer to local regulations.)
5. Ignitor Batteries: For the ignitor batteries, remove the thermometer from the front of the oven. Unscrew the cap and place the battery in the correct way round, before screwing the cap back into position.
6. Digital Temperature Display Connection: To connect the digital temperature display to the thermometer, locate the jack connection in the display port and plug into the rear of the display. Finally, replace the digital temperature display and turn on to test.

Figure 3: Dimensions of the Witt ETNA Rotante Pizza Oven.

5. Kullanım Talimatları

1. Ön ısıtma:
   • To light the gas burner, press the control dial in and turn the dial 90° until you hear a clicking sound and the burner ignites.
   • Hold the control dial in for up to 30 seconds after the burner ignites. Holding this position allows the flame failure device to heat up to temperature.
   • Allow the oven to preheat to 500 °C (950 °F). This typically takes less than 15 minutes due to the booster burner and innovative U-shaped burners.
   • For your first firing, it is highly recommended to put the burner on a medium to low flame for 30 minutes.
2. Pizza Pişirme:
   • Once the oven reaches the desired temperature, carefully slide your pizza onto the rotating stone using a pizza peel.
   • The 360-degree rotating stone will ensure your pizza cooks evenly, providing a perfect leopard-spotted and crispy crust without the need for manual rotation.
   • Pizzas will cook very quickly, often in less than a minute. Monitor closely to prevent overcooking.
   • Adjust the flame intensity using the control knob if the pizza is cooking too fast on top or not enough on the bottom.

Figure 4: The booster burner ensures continuous high heat.

Figure 5: Pizza cooking on the 360-degree rotating stone.

6. Bakım

1. Sakin ol: Always allow the oven to cool down completely before attempting any cleaning or maintenance. The cool-down time can vary but typically takes approximately one and a half hours. Never touch the surface or stone before it has cooled down.
2. Pizza taşının temizlenmesi: Once completely cool, the pizza stone can be cleaned with water and a cloth. Do not use a polypropylene brush on a hot stone, as it can melt and damage the stone.
3. Dış Temizlik: Dış yüzeyleri reklamla silinamp bez. Aşındırıcı temizleyicilerden kaçının.
4. Depolamak: When not in use, especially during adverse weather conditions, it is recommended to cover the oven with a suitable protective cover to prolong its lifespan.

7. Sorun Giderme

Herhangi bir sorunla karşılaşırsanız, lütfen aşağıdaki yaygın sorun giderme adımlarına bakın:

• Brülör Ateşleme Yapmadı: If the burner fails to ignite, wait 5 minutes before trying again. If it continues to fail, please review the detailed troubleshooting guide in the full user manual or contact customer support.
• Pizza Stone Not Heating Evenly: Ensure both the U-shaped main burner and the booster burner are functioning correctly. Verify that the gas supply is adequate and that the oven has been allowed sufficient time to preheat to the target temperature.
• Pizza Bottom Not Cooked / Top Burned: This often indicates the pizza stone is not hot enough, or the flame intensity is too high. Ensure the oven is fully preheated to 500 °C (950 °F) before cooking. Adjust the flame to a lower setting once the pizza is inserted to allow the bottom to cook without burning the top.

8. Özellikler

9. Garanti ve Destek

For detailed warranty information, product registration, and customer support, please visit the official Witt webWeb sitesini ziyaret edin veya yetkili satıcınızla iletişime geçin. Garanti talepleri için satın alma belgenizi saklayın.

Thank you for choosing Witt. Enjoy your delicious homemade pizzas!
