ATN Odin LT 640x480 1-4x 19mm Thermal Monocular User Manual

1. Giriş

This manual provides instructions for the proper use and maintenance of your ATN Odin LT 640x480 1-4x 19mm Thermal Monocular. The Odin LT is a compact, ergonomic, and versatile thermal imaging device designed for observation. It features ATN's Obsidian LT core, offering a hands-free experience when mounted.

Temel özellikler şunlardır:

• Obsidian LT Core: Advanced thermal processing for clear imaging.
• White Hot/Black Hot Mode: Selectable color palettes for displaying thermal signatures.
• Kompakt Tasarım: Fits comfortably in one hand for easy manipulation.
• Yüksek Çözünürlüklü Ekran: 1280x960 display for vivid images.
• Çok Yönlü Montaj: Handheld, helmet, or head-mounted for various observation scenarios.

2. Paket İçeriği

Paketi açtığınızda lütfen aşağıda listelenen tüm öğelerin mevcut ve iyi durumda olduğundan emin olun:

• ATN Odin LT Thermal Monocular

Note: Additional accessories such as mounts or rechargeable batteries may be sold separately.

3. Ürün Bittiview

The ATN Odin LT is designed for intuitive operation with its ergonomic form factor.

Şekil 3.1: Ön taraf view of the ATN Odin LT Thermal Monocular, showing the objective lens and eyepiece.

Şekil 3.2: Diagram illustrating key features of the Odin LT, including the Obsidian LT core, USB-C port, step zoom, ergonomic design, and lightweight construction.

3.1 Bileşenler

• Objektif Mercek: Collects thermal radiation.
• Göz merceği: İçin viewtermal görüntüyü kullanarak.
• Kontrol Düğmeleri: For power, menu navigation, and zoom.
• USB-C Bağlantı Noktası: For charging (with optional rechargeable battery) or data transfer.
• Montaj Noktası: For attaching to helmets or head mounts.

4. Kurulum

4.1 Pil Kurulumu

1. Cihazdaki pil bölmesini bulun.
2. Bölme kapağını açın.
3. Insert the required batteries (type specified in specifications) according to the polarity indicators.
4. Pil bölmesi kapağını güvenli bir şekilde kapatın.

4.2 Montaj Seçenekleri

The Odin LT can be used handheld or mounted for extended observation periods.

• Elde Kullanım: Simply hold the monocular to your eye for observation.
• Helmet/Head Mount: Attach the monocular to a compatible helmet or head mount using the integrated mounting point. Ensure the mount is securely fastened and adjusted for comfortable viewIng.

Şekil 4.1: Example of handheld use of the ATN Odin LT in an outdoor environment.

Şekil 4.2: Kapatmak view of the monocular being used for observation.

5. Kullanım Talimatları

5.1 Güç Açma/Kapatma

• Güç Açık: Press and hold the Power button (typically marked with a power symbol) for approximately 2-3 seconds until the display illuminates.
• Kapat: Press and hold the Power button again for approximately 3-5 seconds until the display turns off.

5.2 Odak Ayarı

The Odin LT features manual focus. Rotate the focus ring on the objective lens until the image appears sharp and clear in the eyepiece.

5.3 Yakınlaştırma İşlevi

Utilize the step zoom feature to adjust the magnification. Refer to the device's on-screen display or specific buttons for zoom control. The monocular offers a 1-4x magnification range.

5.4 Display Modes (White Hot/Black Hot)

The Odin LT provides different thermal display modes to suit various observation conditions:

• Beyaz sıcak: Hot objects appear white, and colder objects appear black.
• Siyah Sıcak: Hot objects appear black, and colder objects appear white.

Cycle through these modes using the designated button (refer to your device's button layout for specifics).

6. Bakım

6.1 Temizlik

• Mercekler: Use a soft, lint-free cloth specifically designed for optics. Gently wipe the lens surfaces. For stubborn smudges, use a small amount of lens cleaning solution.
• Vücut: Monoküler cihazın gövdesini yumuşak bir bezle silin.amp Kumaşı sert kimyasallardan veya aşındırıcı malzemelerden uzak tutun.

6.2 Depolama

When not in use, store the monocular in a cool, dry place, away from direct sunlight and extreme temperatures. If storing for extended periods, remove the batteries to prevent leakage.

7. Sorun Giderme

If you encounter issues with your ATN Odin LT, refer to the following common problems and solutions:

If the problem persists after attempting these solutions, please contact ATN customer support for further assistance.

8. Özellikler

Technical specifications for the ATN Odin LT 640x480 1-4x 19mm Thermal Monocular:

9. Garanti ve Destek

For information regarding warranty coverage, technical support, or service, please refer to the official ATN website or contact ATN customer service directly. Keep your proof of purchase for warranty claims.

Daha fazla bilgi ve iletişim bilgilerini şu adreste bulabilirsiniz: ATN Official Store.
