1. Giriş
Thank you for choosing the AXA Imenso XL Ret retractable Ring Lock. This manual provides essential information for the proper installation, operation, and maintenance of your new bicycle lock. Designed for optimal security and user convenience, the Imenso XL offers robust protection for various bicycle types, including electric bikes and those with wide tires.
Image 1.1: The AXA Imenso XL Ret retractable Ring Lock. This image displays the full view of the black AXA Imenso XL ring lock with a key inserted, highlighting its robust design.
2. Ürün Özellikleri
The AXA Imenso XL Ret retractable Ring Lock is engineered with several key features to ensure maximum security and ease of use:
- Maximum Security (Level 12): Constructed from hardened steel with an anti-drilling cylinder, providing strong theft protection. Ideal for electric bikes, speed pedelecs, cargo bikes, and city bikes.
- Plug-in Compatibility: Designed to work seamlessly with AXA ULC chains and UPI plug-in cables, allowing you to secure your bicycle to fixed objects for enhanced security.
- Kullanıcı Dostu Tasarım: Features an ergonomic push button for comfortable operation, a child safety feature, and a design where the key remains in place when the lock is unlocked, preventing accidental loss.
- Flexible & Wide Fit: An extra-wide 92mm opening accommodates wide fenders or balloon tires. Multiple mounting options are available for various frame types.
- AXA Key Service: In case of a lost key, an extra key can be ordered via the official AXA online key service.
Image 2.1: Safety Index 12. This graphic illustrates the high security rating of the AXA Imenso XL lock, indicating its robust anti-theft capabilities.
3. Kurulum ve Kurulum
The AXA Imenso XL can be mounted in several ways to suit your bicycle frame.
3.1 Standard Mounting
The lock is typically mounted directly onto existing mounting holes in the bicycle frame. Ensure these holes are present and correctly aligned before proceeding.
Image 3.1: Mounting on a bicycle frame. This image shows the AXA Imenso XL lock being attached to the rear frame of a bicycle, demonstrating the standard mounting process.
3.2 Mounting without Frame Holes (Optional)
If your bicycle frame does not have pre-drilled mounting holes for a ring lock, you can use AXA Flex mount strips (sold separately) for installation. Follow the instructions provided with the Flex mount strips for proper attachment.
3.3 Wide Tire Compatibility
The Imenso XL features an extra-wide opening of 92 mm, making it suitable for bicycles with wide fenders or balloon tires.
Image 3.2: Wide opening dimensions. This image highlights the 92mm internal width of the AXA Imenso XL lock, illustrating its compatibility with wider tires and fenders.
4. Kullanım Talimatları
4.1 Locking Your Bicycle
- Ensure the lock is properly mounted on your bicycle frame.
- Align the retractable shackle with the wheel spokes.
- Press the ergonomic push button to engage the lock. The shackle will retract, securing the wheel.
- Remove the key. The lock is now engaged.
4.2 Unlocking Your Bicycle
- Anahtarı kilit silindirine yerleştirin.
- Turn the key to disengage the lock. The shackle will extend, releasing the wheel.
- The key will remain in the lock when it is unlocked, preventing accidental loss while riding.
Image 4.1: Key in unlocked position. This close-up image shows the key inserted into the AXA Imenso XL lock, illustrating how the key remains in the cylinder when the lock is open.
4.3 Using Plug-in Accessories
For additional security, the AXA Imenso XL is compatible with AXA ULC plug-in chains or UPI plug-in cables.
- Secure your bicycle with the ring lock as described above.
- Insert the plug-in pin of the ULC chain or UPI cable into the designated slot on the side of the Imenso XL lock.
- Wrap the chain/cable around a fixed object (e.g., lamppost, bike rack) and then insert the other end into the lock's plug-in slot.
- The plug-in accessory will be secured by the main lock mechanism.
Image 4.2: Plug-in compatibility. This image demonstrates how an AXA plug-in chain is inserted into the AXA Imenso XL lock, enabling additional security by attaching the bike to a fixed object.
5. Bakım
Regular maintenance ensures the longevity and smooth operation of your AXA Imenso XL lock.
- Temizlik: Periodically wipe the lock body with a damp Kir ve pisliği temizlemek için bez kullanın. Sert kimyasallardan kaçının.
- Yağlama: Apply a small amount of lock lubricant (e.g., graphite-based or silicone spray) to the keyhole and moving parts of the shackle mechanism every 6-12 months, or more frequently in dusty or wet conditions.
- Anahtar Bakım: Keep your keys clean and avoid bending them. Do not force a key into the lock if it feels stiff.
6. Sorun Giderme
If you encounter issues with your AXA Imenso XL lock, refer to the following common solutions:
- Key is stiff or difficult to turn:
- Apply lock lubricant to the keyhole and insert/remove the key several times.
- Anahtarın bükülmüş veya hasar görmüş olup olmadığını kontrol edin. Varsa yedek anahtar kullanın.
- Shackle does not retract/extend smoothly:
- Ensure no debris is obstructing the shackle mechanism. Clean the area.
- Lubricate the moving parts of the shackle.
- Kilit devreye girmiyor:
- Verify that the lock is correctly aligned with the wheel.
- Check for any foreign objects preventing the shackle from closing fully.
If problems persist, contact AXA customer support for further assistance.
7. Özellikler
| Özellik | Detay |
|---|---|
| Marka | AXA |
| Model Adı | AXA Imenso X Large Ret retractable |
| Model Numarası | 720018006121 |
| Kilit Tipi | Anahtar Kilidi |
| Güvenlik Seviyesi | 12 (AXA Safety Index) |
| Malzeme | Alaşımlı Çelik |
| Renk | Siyah |
| Ürün Boyutları (U x G x Y) | 6.3 x 6.7 x 1.4 inç (16 x 17 x 3.5 cm) |
| Ürün Ağırlığı | 1.69 pound (0.77 kg) |
| Açılış genişliği | 92 mm (Extra-Large) |
| Özel Özellikler | Heavy Duty, Anti Theft, Portable, Plug-in Compatible, Child Safety Feature |
| Önerilen Kullanımlar | Securing bicycles (Electric Bikes, Speed Pedelecs, Cargo Bikes, City Bikes) |
8. Garanti ve Destek
8.1 AXA Key Service
In the event of a lost or damaged key, an extra key can be conveniently ordered through the official AXA online key service. Visit the AXA website for details on how to place an order.
Image 8.1: AXA Key Service. This image highlights the AXA Key Service, indicating that replacement keys can be quickly and safely obtained.
8.2 Ürün Garantisi
AXA products are manufactured to high-quality standards. For specific warranty terms and conditions, please refer to the documentation included with your purchase or visit the official AXA webSite. Satın alma belgenizi garanti talepleriniz için saklayın.
8.3 Müşteri Desteği
For any questions, technical support, or assistance with your AXA Imenso XL Ret retractable Ring Lock, please contact AXA customer support through their official channels.
