This manual provides comprehensive instructions for the VR-robot V9 Pro Motorcycle Helmet Intercom Communication System. It covers setup, operation, maintenance, and troubleshooting to ensure optimal performance and user safety. The V9 Pro is designed to provide clear communication, stereo music, and FM radio functionality for motorcycle riders.
Image: The VR-robot V9 Pro main unit with attached speakers and microphone, illustrating the complete system components.
Paket İçeriği
Aşağıda listelenen tüm öğelerin paketinizde bulunduğunu doğrulayın:
Image: A visual representation of all components included in the VR-robot V9 Pro package, numbered for easy identification.
- Cırt cırtlı
- 3M yapıştırıcı
- Fixed Velcro
- Fixed Velcro (additional)
- Microphone Protective Cover
- Kulaklık Klipsi
- Kullanıcı Kılavuzu
- Hoparlör Pedi
- Şarj kablosu
- Mikrofon Uzatma Kablosu
- gizli mikrofon
- V9 Pro Main Unit
- Direk Mikrofonu
- Hoparlör Kiti
Kurulum ve Yükleme
The V9 Pro offers two installation methods: Velcro and metal earphone clip. Choose the method best suited for your helmet type.
1. Cihazın Şarj Edilmesi
Before first use, fully charge the V9 Pro. Connect the provided charging cable to the device and a USB power source. A full charge takes approximately 2.5 hours.
Image: Illustration showing the 850mAh battery capacity and charging time of 2.5 hours, with a standby time of up to 200 hours.
2. Kaska Takma
The V9 Pro is compatible with both open helmets and full-face helmets. No additional screws are needed, preserving the helmet's appearance.
Image: Various types of motorcycle helmets, demonstrating the versatility of the V9 Pro's installation across different helmet designs.
Using the Earphone Clip:
- Attach the earphone clip to the side of your helmet.
- Slide the V9 Pro main unit onto the clip until it securely locks into place.
- Insert the speakers into the helmet's ear pockets, ensuring they are positioned directly over your ears for optimal sound.
- Attach the microphone (soft or rod-type) to a suitable position inside the helmet, near your mouth, using the microphone extension cable if needed.
Cırt cırt kullanarak:
- Clean the desired installation area on your helmet.
- Apply the fixed Velcro strips to the helmet surface.
- Attach the V9 Pro main unit to the Velcro.
- Proceed with speaker and microphone installation as described above.
Image: A step-by-step visual guide demonstrating how to install the V9 Pro unit onto a motorcycle helmet using the provided clip and connecting the speakers and microphone.
Kullanım Talimatları
The V9 Pro features multi-function buttons designed for easy operation, even while wearing gloves.
Image: A comparison illustrating the ease of operating the V9 Pro's large buttons with both bare hands and gloved hands.
1. Güç Açma/Kapatma
- Güç Açık: Güç düğmesini 3 saniye basılı tutun.
- Kapat: Güç düğmesini 3 saniye basılı tutun.
2. Bluetooth Eşleştirme
The V9 Pro uses Bluetooth 3.0 for connectivity.
- Cihazın kapalı olduğundan emin olun.
- Press and hold the Multi-function button until the indicator light flashes red and blue, indicating pairing mode.
- On your mobile device, search for "V9 Pro" in the Bluetooth settings and select to pair.
- Once paired, the indicator light will turn blue.
3. İnterkom İletişimi
The V9 Pro supports intercom communication between two riders up to 800 meters (2625 feet).
Image: Two motorcyclists communicating, with an overlay indicating an intercom distance of up to 800 meters.
- To initiate intercom, ensure both V9 Pro units are powered on and within range.
- Press the Intercom button on one unit to connect.
- To end intercom, press the Intercom button again.
4. Telefon Görüşmeleri
The V9 Pro supports hands-free calling with automatic answer functionality.
Image: A motorcyclist riding, with an overlay of a smartphone screen showing an incoming call, illustrating the automatic call answering feature.
- Cevap Çağrısı: Incoming calls are automatically answered after a few rings. You can also short press the Multi-function button to answer.
- Çağrı Sonu: Çok fonksiyonlu düğmeye kısa süre basın.
- Çağrıyı Reddet: Çok işlevli düğmeyi 2 saniye basılı tutun.
- Son Numarayı Tekrar Ara: Çok fonksiyonlu düğmeye iki kez basın.
5. Müzik Çalma
Enjoy stereo music with DSP noise reduction technology for clear audio.
Image: A motorcyclist wearing a helmet, with musical notes floating around, indicating the stereo music playback capability of the V9 Pro.
- Oynat/Duraklat: Çok fonksiyonlu düğmeye kısa süre basın.
- Sonraki Parça: Sesi Açma tuşuna kısa basın.
- Önceki parça: Sesi Azaltma düğmesine kısa basın.
- Sesi aç: Sesi Açma tuşuna uzun basın.
- Sesi kıs: Sesi Azaltma düğmesine uzun basın.
6. FM Radyo
Tune into FM radio for real-time road conditions and entertainment.
Image: A motorcyclist riding, with a transparent map overlay showing radio waves, symbolizing the FM radio function for real-time information.
- FM Radyoyu Açma/Kapatma: FM düğmesine basın.
- Kanalları Tara: FM düğmesine basılı tutarak mevcut istasyonları otomatik olarak tarayın ve kaydedin.
- Gelecek istasyon: Sesi Açma tuşuna kısa basın.
- Önceki İstasyon: Sesi Azaltma düğmesine kısa basın.
7. Voice Prompts and GPS
The V9 Pro provides voice prompts for device status and can relay GPS voice instructions from your paired smartphone.
Bakım
Proper maintenance ensures the longevity and optimal performance of your V9 Pro system.
- Temizlik: Yumuşak bir d kullanınamp cloth to clean the main unit and speakers. Avoid using harsh chemicals or abrasive cleaners.
- Suya Dayanıklılık: The V9 Pro has a daily-use waterproof design, allowing normal operation in bad weather. However, avoid submerging the device in water.
- Depolamak: When not in use for extended periods, store the device in a cool, dry place. Ensure it is fully charged before storage to preserve battery health.
- Pil Bakım: Recharge the battery regularly, even if not frequently used, to maintain its capacity.
Image: The V9 Pro unit with water droplets on its surface, demonstrating its waterproof capabilities against rain.
Sorun giderme
If you encounter issues with your V9 Pro, refer to the following common problems and solutions:
| Sorun | Olası Neden | Çözüm |
|---|---|---|
| Cihaz açılmıyor. | Pil zayıf. | Cihazınızı en az 2.5 saat şarj edin. |
| Telefonla eşleştirilemiyor. | Device not in pairing mode; Bluetooth off on phone; device already paired with another device. | Ensure V9 Pro is in pairing mode (flashing red/blue). Turn on phone's Bluetooth. Disconnect from other devices. |
| İnterkom bağlantısı kurulmuyor. | Units out of range; units not properly paired for intercom. | Ensure units are within 800m. Re-initiate intercom connection. |
| Ses kalitesi düşük/gürültülü. | Microphone/speakers improperly positioned; external interference. | Adjust microphone closer to mouth. Ensure speakers are centered over ears. Move away from strong electromagnetic fields. |
| Düğmeler çalışmıyor. | Cihaz donmuş; pil seviyesi düşük. | Try restarting the device. Charge the device. |
If the problem persists, please contact VR-robot customer support.
Özellikler
| Özellik | Detay |
|---|---|
| Model Adı | V9 Pro |
| Bağlantı Teknolojisi | Kablosuz (Bluetooth) |
| Bluetooth Sürümü | 3.0 |
| interkom aralığı | Up to 800 meters (2625 feet) for 2 riders |
| Pil Kapasitesi | 850mAh Lityum Pil |
| Şarj Süresi | 2.5 Saat |
| Sürekli Çalışma Süresi | 10 hours (Play time: 12 hours) |
| Bekleme Süresi | 200 Saate Kadar |
| Gürültü Kontrolü | Active Noise Cancellation (DSP) |
| Su Direnç Seviyesi | Waterproof (Daily-use) |
| Mikrofon Seçenekleri | Soft microphone, Rod-type hard microphone |
| Kontrol Türü | Call Control, Noise Control, Voice Control, Volume Control (Multi-function buttons) |
| Boyutlar | 3.26 x 1.73 x 1.02 inç |
| Ürün Ağırlığı | 1.94 Ons |
Garanti ve Destek
VR-robot is committed to providing satisfactory solutions. If you have any questions or require assistance with your V9 Pro, please contact customer support.
Destek Ekibiyle İletişime Geçin:
- Refer to the contact information provided in your product packaging or on the official VR-robot webalan.
- For Amazon purchases, you can typically click "VR robot" on the product page and then "ASK A QUESTION" for support.
Image: An image depicting customer service representatives, symbolizing the availability of support for VR-robot products.
