iZEEKER Dash Cam 1080P User Manual

1. Ürün Bittiview

The iZEEKER Dash Cam GD100 is a high-definition 1080P car driving recorder designed to capture clear footage of your journeys. It features a 3-inch LCD display, 170° wide-angle lens, G-Sensor for emergency recording, loop recording, and parking mode for comprehensive vehicle surveillance.

Resim: Ön view of the iZEEKER Dash Cam GD100, showcasinKompakt tasarımı ve lensiyle dikkat çekiyor.

Image: The iZEEKER Dash Cam GD100 attached to its suction cup mount, ready for windshield installation.

2. Paket İçeriği

Lütfen paketi aşağıdaki öğeler açısından kontrol edin:

• iZEEKER Dash Cam GD100
• Emme Kupası Dağı
• Araba Şarj Cihazı
• USB kablosu
• Kullanıcı Kılavuzu
• 64GB Micro SD Card (if included with your specific package)
• Card Reader (if included with your specific package)

3. Kurulum ve Kurulum

3.1 Hafıza Kartının Takılması

Before first use, insert a high-speed Class 10 or higher Micro SD card (up to 64GB recommended) into the dash cam's memory card slot. Ensure the card is inserted correctly until it clicks into place. It is recommended to format the card within the dash cam's settings before initial use.

3.2 Dash Cam'in Montajı

1. Clean the area on your windshield where you intend to mount the dash cam. Ensure it is free from dust and grease for optimal suction.
2. Vantuzlu montaj aparatını araç kamerasına takın.
3. Press the suction cup firmly against the windshield and flip the lever to secure it. Position the dash cam so that it does not obstruct your view Yolun.
4. Adjust the lens angle to ensure it captures the road ahead clearly. The 170° wide-angle lens provides extensive coverage.

Image: The iZEEKER Dash Cam GD100 securely mounted on a car's windshield, positioned to capture the road ahead.

3.3 Güç Bağlantısı

Connect the car charger to the dash cam's power input port and plug the other end into your vehicle's 12V power outlet (cigarette lighter socket). The dash cam will automatically power on and begin recording when your vehicle starts.

Image: The iZEEKER Dash Cam GD100 connected to the car's power supply, with the cable neatly routed.

4. Araç Kamerasının Kullanımı

4.1 Güç Açma/Kapatma

• Otomatik: The dash cam powers on and off automatically with your vehicle's ignition.
• Manuel: Cihazı manuel olarak açmak veya kapatmak için Güç düğmesini basılı tutun.

4.2 Kayıt Modları

• Döngü Kaydı: The dash cam continuously records video in segments (e.g., 1, 3, or 5 minutes). When the memory card is full, the oldest unlocked video files üzerine yazılır.
• G-Sensörü (Acil Durum Kaydı): In the event of a sudden impact or collision, the built-in G-Sensor automatically detects the event and locks the current video filedöngü kaydı tarafından üzerine yazılmasını önler. Bunlar files are stored in a separate "Event" folder.
• Park Modu: When enabled, the dash cam will automatically start recording if it detects a vibration or motion while your vehicle is parked and the ignition is off. This feature requires a continuous power supply (e.g., a hardwire kit, sold separately).

Image: Illustration of the Intelligent Parking Monitoring feature, showing the dash cam's ability to record events when the vehicle is unattended, protecting personal property.

4.3 Geniş Dinamik Aralık (WDR)

The WDR function helps the dash cam perform optimally in various lighting conditions, such as high contrast or low light. It balances exposure to ensure clear video recording, preventing overexposure in bright areas and underexposure in dark areas, especially useful for night vision.

Image: Visual representation of the WDR (Wide Dynamic Range) function, demonstrating how it adjusts light to prevent overly bright or dark areas in recordings, ensuring a balanced and clear image.

4.4 Menü Gezintisi ve Ayarlar

Use the physical buttons on the side or bottom of the dash cam to navigate through the menu options displayed on the 3-inch LCD screen. Common settings include video resolution, loop recording duration, G-Sensor sensitivity, parking mode, date/time stamp, and memory card formatting.

4.5 Viewing Recorded Footage

Yapabilirsiniz view recorded videos directly on the dash cam's LCD screen by entering playback mode. Alternatively, remove the Micro SD card and insert it into a computer using a card reader to access and transfer files.

5. Bakım

• Lens ve Ekranın Temizlenmesi: Use a soft, lint-free cloth to gently wipe the dash cam's lens and LCD screen. Avoid using abrasive cleaners or solvents that could damage the surfaces.
• Hafıza Kartı Bakımı: Regularly format your Micro SD card (at least once a month) within the dash cam to maintain optimal performance and prevent data corruption. Replace the memory card if you experience frequent errors or degraded performance.
• Sıcaklık Hususları: Araç içi kamerayı uzun süre aşırı sıcaklıklara maruz bırakmaktan kaçının. Araç doğrudan güneş ışığı altında park edilmişse, araç içi kamerayı çıkarmayı veya güneşlik kullanmayı düşünün.

6. Sorun Giderme

For more detailed troubleshooting, please refer to the full user manual available for download from the iZEEKER website veya sağlanan PDF belgesi: Kullanım Kılavuzu (PDF).

7. Özellikler

8. Garanti ve Destek

iZEEKER is committed to providing premium products and excellent customer service. Your iZEEKER Dash Cam GD100 comes with comprehensive support:

• 24 Saat Müdahale: Customer service inquiries are responded to quickly and professionally within 24 hours.
• 30 Günlük İade Politikası: Enjoy a 30-day no-reason return or exchange period from the date of purchase.
• 365 Günlük Değiştirme: Replacement parts and accessories are available within 365 days of purchase.
• Ömür Boyu Satış Sonrası Servis: iZEEKER provides lifetime after-sales service for every customer.

For any questions, technical assistance, or warranty claims, please contact iZEEKER customer support through their official channels or visit the iZEEKER Store on Amazon.
