1. Giriş
Satın aldığınız için teşekkür ederizasing the KOIOS 400W Personal Blender. This manual provides important information on how to safely operate, maintain, and troubleshoot your new appliance. Please read it thoroughly before first use and keep it for future reference.
Temel Özellikler:
- Güçlü 400W Motor: Ensures efficient blending and nutrient extraction.
- Çok Yönlü Bıçak Sistemi: Includes a 6-blade assembly for blending and a 1-blade assembly for grinding.
- Yüksek Hızlı Dönüş: Achieves up to 25,000 rotations per minute for smooth results.
- Dual Portable Cups: Two 500ml blending cups with travel lids for on-the-go convenience.
- Öğütme Kapasitesi: A 300ml grinding cup for coffee beans, spices, and nuts.
- Güvenlik Özellikleri: Equipped with overheat protection and a safety lock mechanism.
- Gıdaya Uygun Malzemeler: Constructed from BPA-free, non-toxic, and safe materials.
- Kolay Temizlenir: Detachable parts for simple and thorough cleaning.
Image: The KOIOS Personal Blender with its various attachments, showcasinçok yönlülüğü.
2. Ürün Bileşenleri
Your KOIOS Personal Blender package includes the following parts:
- Blender Base (Motor Unit): Ana güç ünitesi.
- 6-Blade Assembly: For blending fruits, vegetables, and ice.
- 1-Blade Assembly: For grinding dry ingredients like coffee beans.
- 500ml Blending Cups (x2): Large capacity cups for smoothies and juices.
- 300ml Grinding Cup (x1): Smaller cup specifically for grinding.
- Travel Lids (for 500ml cups): Allows you to take your drinks on the go.
- Kullanım Kılavuzu: Bu kullanım kılavuzu.
Resim: Ayrıntılı view of the blade assemblies, safety lock, and ventilation features.
3. Kurulum
Before first use, wash all detachable parts (cups, lids, blade assemblies) with warm soapy water, rinse thoroughly, and dry completely.
Montaj Adımları:
- Place the blender base on a clean, dry, and stable surface. Ensure it is near a power outlet.
- Choose the appropriate cup (500ml for blending, 300ml for grinding) and blade assembly (6-blade for blending, 1-blade for grinding).
- Add your desired ingredients into the cup. MAX dolum çizgisini aşmayın. For blending with ice, always add liquid along with the ice.
- Screw the chosen blade assembly firmly onto the open end of the cup, ensuring a tight seal.
- Invert the cup and blade assembly, then align the tabs on the cup with the slots on the blender base.
- Press down gently and twist the cup clockwise until it locks securely into place. The blender will not operate unless the cup is properly locked.
Image: Visual guide for preparing and blending ingredients.
4. Operasyon
Blending (Smoothies, Juices, Shakes):
- Use the 500ml blending cup and the 6-blade assembly.
- Add your desired fruits, vegetables, and liquid. For best results, ensure there is enough liquid to cover the blades.
- Securely attach the blade assembly to the cup and lock the cup onto the blender base as described in the Setup section.
- Blenderi elektrik prizine takın.
- Press and hold the power button (or twist the cup further if it's a twist-to-activate model) to start blending.
- Blend for approximately 30-60 seconds, or until your desired consistency is achieved.
- Önemli: Do not operate the blender continuously for more than 1 minute to prevent overheating. If blending for longer, allow the motor to rest for at least 20 minutes between cycles.
- Once blending is complete, release the button (or twist the cup counter-clockwise to unlock) and unplug the unit.
- Remove the cup, unscrew the blade assembly, and attach a travel lid if taking your drink on the go.
Grinding (Coffee Beans, Spices, Nuts):
- Use the 300ml grinding cup and the 1-blade assembly.
- Add dry ingredients such as coffee beans, pepper, or small nuts. Do not add any liquids when grinding.
- Securely attach the 1-blade assembly to the grinding cup and lock the cup onto the blender base.
- Blenderi elektrik prizine takın.
- Operate in short pulses (5-10 seconds at a time) until the desired fineness is achieved.
- After grinding, release the button (or twist to unlock) and unplug the unit.
- Carefully remove the cup and detach the blade assembly.
Image: Blending helps maximize nutrient absorption from fruits and vegetables.
5. Bakım ve Temizlik
Proper cleaning and maintenance will extend the life of your blender.
Temizleme Adımları:
- Temizlemeden önce daima blenderin fişini prizden çekin.
- Separate the cup, blade assembly, and travel lid from the motor base.
- Rinse the cups, lids, and blade assemblies under running water immediately after use. Use a mild dish soap and a brush to clean around the blades carefully.
- Do NOT immerse the motor base in water or any other liquid. Motor tabanını reklamla silinamp temizlemek için bez.
- Ensure all parts are thoroughly dried before reassembling or storing to prevent rust and odor.
Depolamak:
Store the blender and its components in a dry, clean place away from direct sunlight and moisture.
Image: Easy cleaning of the detachable blade assembly and cup.
6. Sorun Giderme
Blenderınızla ilgili herhangi bir sorunla karşılaşırsanız lütfen aşağıdaki yaygın sorunlara ve çözümlere bakın:
| Sorun | Olası Neden | Çözüm |
|---|---|---|
| Blender başlamıyor. | Cup not properly locked onto the base. Güç kablosu takılı değil. Aşırı ısınma koruması etkinleştirildi. | Ensure the cup is twisted clockwise until securely locked. Güç kablosunun çalışan bir prize sağlam bir şekilde takılı olup olmadığını kontrol edin. Unplug the blender and let it cool down for at least 20 minutes. |
| Burning smell or motor is hot. | Overloading or continuous operation. | Unplug immediately. Reduce the amount of ingredients or add more liquid. Let the unit cool for 20 minutes before resuming. Do not operate for more than 1 minute continuously. |
| Bardaktan sızıyor. | Bıçak tertibatı sıkılmamış. Sealing ring improperly placed or damaged. Overfilling the cup. | Ensure the blade assembly is screwed on tightly. Check the sealing ring for proper placement and any damage. Do not fill ingredients beyond the MAX line. |
| Malzemeler düzgün bir şekilde karışmıyor. | Yetersiz sıvı. Too many solid ingredients. Ingredients stuck. | Daha fazla sıvı ekleyin. Reduce the amount of solid ingredients. Briefly remove the cup, shake it, and reattach to redistribute ingredients. |
7. Özellikler
| Özellik | Şartname |
|---|---|
| Model Numarası | BL219B |
| Güç | 400W |
| Dönme Hızı | 25,000 dev/dak'ya kadar |
| Karıştırma Kabı Kapasitesi | 500 ml |
| Öğütme Kabı Kapasitesi | 300 ml |
| Bıçak Malzemesi | 304 Paslanmaz Çelik |
| Cup Material | Food-grade PC |
| Base/Blade Cover Material | Yüksek kaliteli ABS |
| Motor Malzemesi | Saf Bakır |
| Paket Boyutları | 29.5x24.5x12.7 cm |
| Paket Ağırlığı | 1.95 kilo |
8. Garanti ve Destek
Your KOIOS Personal Blender comes with a 1 yıllık üretici garantisi satın alma tarihinden itibaren.
This warranty covers defects in materials and workmanship under normal use. It does not cover damage resulting from misuse, accidents, unauthorized modifications, or failure to follow the instructions in this manual.
If you experience any issues with your product, especially initial defects, please contact our customer support team. Please have your purchase information and model number (BL219B) ready when contacting support.
For further assistance or inquiries, please refer to the contact information provided with your purchase or visit the official KOIOS webalan.
