Anlapus 8-Channel 720P Hybrid DVR Security System Recorder User Manual

1. Ürün Bittiview

The Anlapus 8-Channel 720P Hybrid Digital Video Recorder (DVR) is designed for comprehensive security surveillance. This 4-in-1 system supports various camera types including 960H Analog, 720P/1080P AHD, 720P/1080P TVI, and CVI cameras across all 8 channels. It features customizable motion detection with instant email alerts and supports remote access via a dedicated mobile application.

Şekil 1: Anlapus 8-Channel DVR highlighting key features like 1080N/720P recording, H.264+ compression, 4-in-1 compatibility, HDMI output, PTZ support, motion detection, email alerts, remote access, mouse operation, and USB backup.

Paket İçeriği

• 1 x Anlapus 8-Channel DVR
• Güç Adaptörü
• USB Mouse
• Kullanım Kılavuzu (bu belge)
• (Note: Hard drive may be pre-installed or sold separately depending on the specific package.)

Şekil 2: The Anlapus 720P 4-in-1 Security Video DVR Recorder, showcasing its compact design and suitability for various security camera setups.

2. Kurulum ve Kurulum

Follow these steps to set up your Anlapus DVR system. Ensure all components are present before beginning installation.

2.1 DVR'ı bağlama

1. Kameraları Bağlayın: Attach your security cameras to the "VIDEO IN" BNC ports on the back of the DVR. The DVR supports up to 8 cameras.
2. Monitörü Bağla: Connect a monitor to the DVR using either the HDMI or VGA port. An HDMI cable (not included) or VGA cable (not included) can be used.
3. Fareyi Bağla: Plug the included USB mouse into one of the USB 2.0 ports on the DVR.
4. Ağ Bağlantısı (İsteğe bağlı): uzaktan kumanda için viewing and email alerts, connect the DVR to your router using an Ethernet cable (not included) via the "NETWORK" port.
5. Gücü bağlayın: Plug the power adapter into the "DC 12V" power input on the DVR, then connect it to a power outlet. The DVR will power on automatically.

Şekil 3: Rear panel of the Anlapus DVR, showing video input (BNC), audio input/output, VGA, HDMI, network (Ethernet), USB, and power ports. Dimensions are also indicated.

2.2 Sabit Disk Kurulumu (Gerekirse)

This DVR model often comes with a pre-installed 1TB security-grade hard drive. If your unit did not include one or if you need to replace it, follow the manufacturer's instructions for opening the casing and connecting a compatible SATA hard drive. Ensure the DVR is powered off before performing any internal installations.

2.3 İlk Yapılandırma

Upon first power-on, the DVR will guide you through an initial setup wizard. This typically includes setting the date and time, creating a password, and configuring network settings. Follow the on-screen prompts using the connected mouse.

Şekil 4: The DVR supports multiple output options, including HDMI and VGA, allowing connection to various display devices like TVs and computer monitors.

3. DVR Sisteminin Çalıştırılması

3.1 Kayıt Modları

The Anlapus DVR offers flexible recording options:

• Manuel Kayıt: Gerektiğinde kaydı manuel olarak başlatın ve durdurun.
• Hareket Algılama Kaydı: The DVR records only when motion is detected in the camera's field of view, saving storage space.
• Planlanmış Kayıt: Sürekli kayıt için belirli zaman ve günler belirleyin.

These settings can be configured through the DVR's main menu, typically found under "Record" or "Schedule" options.

Şekil 5: Visual representation of different recording modes: Manual Recording, Motion Detection Recording, and Scheduled Recording, with a timeline showing recorded events.

3.2 Hareket Algılama ve Uyarılar

Hareket algılamayı yapılandırmak için:

1. Access the DVR's main menu and navigate to "Alarm" or "Motion Detect" settings.
2. Select the camera(s) for which you want to enable motion detection.
3. Define the detection area by drawing a grid on the screen.
4. Configure sensitivity levels.
5. Enable "Email Alert" to receive notifications with images when motion is detected. Ensure your network settings and email server details are correctly configured.
6. Enable "Mobile Push" for app notifications.

Şekil 6: Illustration of the motion detection feature, showing an area being monitored and an instant email alert/app notification being triggered upon detection.

3.3 Mobil Uygulama Aracılığıyla Uzaktan Erişim

The Anlapus DVR supports remote viewing on Android and iOS devices. To set up:

1. Download the free Anlapus app from your device's app store.
2. Open the app and register an account if required.
3. Add your DVR by scanning the QR code displayed on the DVR's monitor (usually found in the network settings or P2P menu).
4. Bir kez eklendiğinde, şunları yapabilirsiniz: view live feeds, playback recordings, and receive push notifications from anywhere with an internet connection.

Şekil 7: Steps to connect to the Anlapus App: Quick & Easy Connection, Download Free Anlapus App, and Enjoy Live View, demonstrating the mobile interface.

Şekil 8: The Anlapus app interface on a smartphone, illustrating local and remote access capabilities for live viewing and playback on Windows, iOS, and Android devices.

3.4 Oynatma ve Yedekleme

Yırttıview kaydedilmiş footage:

• Access the "Playback" menu on the DVR.
• Select the date, time, and camera channel you wish to review.
• Kayıtlar arasında gezinmek için zaman çizelgesini kullanın.
• Yiyecekleri desteklemek içintage, insert a USB flash drive into a USB port on the DVR. Select the desired footage and use the backup function in the menu.

4. Bakım

4.1 Sabit Sürücü Yönetimi

The DVR's 1TB hard drive provides continuous recording. When the hard drive is full, the system is typically configured to overwrite the oldest footage automatically. You can adjust this setting in the DVR's storage or record menu. Regularly back up important footage to an external USB drive.

4.2 Temizlik

Keep the DVR unit clean and free from dust to ensure proper ventilation. Use a soft, dry cloth for cleaning. Do not use liquid cleaners or aerosols directly on the unit.

4.3 Firmware Güncellemesi

Periodically check the Anlapus official website for firmware updates. Updating firmware can improve system performance, add new features, or resolve known issues. Follow the provided instructions carefully when performing firmware updates to avoid damaging the device.

5. Sorun Giderme

If you encounter issues not listed here or require further assistance, please contact Anlapus customer support.

6. Özellikler

Şekil 9: The Anlapus HD 4-in-1 Hybrid DVR demonstrating compatibility with various camera technologies: HD-TVI, CVBS, CVI, and AHD.

7. Garanti ve Destek

7.1 Ürün Garantisi

The Anlapus 8-Channel 720P Hybrid DVR comes with a 2 yıllık garanti from the date of purchase. This warranty covers manufacturing defects and ensures the product functions as intended under normal use. If the product ceases to function within the first year due to a defect, it will be replaced.

7.2 Teknik Destek

Anlapus provides ömür boyu teknik destek for this product. For any technical assistance, troubleshooting, or inquiries regarding your DVR system, please contact Anlapus customer support. Contact information can typically be found on the official Anlapus websitede veya ürün ambalajında ​​yer almamaktadır.
