Klarstein Bornholm 2000W Electric Convector Heater User Manual

1. Önemli Güvenlik Bilgileri

Please read this manual carefully before using the Klarstein Bornholm 2000W Electric Convector Heater. Keep these instructions for future reference. Failure to follow these safety guidelines may result in electric shock, fire, or injury.

• Aşırı Isınma Koruması: The heater is equipped with an automatic overheat protection system. If the unit overheats, it will automatically shut off. Unplug the heater and allow it to cool down before restarting. Ensure proper ventilation and do not cover the heater.
• Suya Dayanıklılık (IP24): This heater has an IP24 rating, making it suitable for use in damp rooms like bathrooms, provided it is installed according to local electrical regulations and is not directly exposed to water spray. Do not immerse the unit in water.
• Çocuk Güvenlik Kilidi: The control panel features a child safety lock to prevent accidental changes to settings.
• Atama: Do not place the heater directly below a power outlet. Maintain a safe distance from flammable materials, furniture, and curtains.
• Güç Kaynağı: Güç kaynağı hacmini sağlayıntage matches the rating on the heater's label. Do not use extension cords unless absolutely necessary and ensure they are rated for the heater's power consumption.
• Bakım: Temizlik veya herhangi bir bakım işlemi yapmadan önce ısıtıcının fişini daima çekin.

2. Ürün Bittiview

The Klarstein Bornholm 2000W Electric Convector Heater is designed to provide efficient and comfortable heating for your home. It features a sleek design and user-friendly controls.

Temel Özellikler:

• Güç Çıkışı: 2000W for effective heating of rooms up to 40 m².
• Isıtma Elemanı: X-shape heating element for rapid and uniform heat distribution.
• Termostat: Adjustable thermostat to maintain desired room temperature.
• Zamanlayıcı Fonksiyonu: Otomatik kapanma için programlanabilir zamanlayıcı.
• Kontrol: Intuitive touch control panel and remote control for convenient operation.
• Çok Yönlü Yerleştirme: Can be used freestanding with included wheels or wall-mounted with the provided kit.
• Emniyet: Overheat protection and child safety lock.
• Tasarım: Elegant glass panel with minimalist display.

Bileşenler:

• Convector Heater Unit
• Uzaktan kumanda
• Duvar Montaj Kiti
• Floor Wheels (for freestanding use)

Şekil 2.1: Ön view of the Klarstein Bornholm 2000W Electric Convector Heater.

Şekil 2.2: Ayrıntılı view of the touch control panel on the heater.

Figure 2.3: The heater shown with its accompanying remote control.

3. Kurulum ve Kurulum

The Klarstein Bornholm heater offers flexible installation options: freestanding or wall-mounted.

3.1 Freestanding Installation:

1. Isıtıcıyı ve tüm parçalarını dikkatlice ambalajından çıkarın.
2. Attach the provided floor wheels to the base of the heater using the screws. Ensure they are securely fastened.
3. Place the heater on a flat, stable surface, ensuring adequate clearance from walls and other objects (minimum 1 meter from flammable materials).

3.2 Duvara Monte Kurulum:

1. Select a suitable wall location, away from water sources and flammable materials. Ensure the wall can support the heater's weight.
2. Using the provided wall mounting kit, mark the drilling points on the wall according to the template or instructions.
3. Delikleri açın ve dübelleri takın.
4. Montaj braketlerini duvara sabitleyin.
5. Carefully hang the heater onto the wall brackets, ensuring it is level and securely attached.

Figure 3.1: The heater can be used freestanding with wheels or mounted on a wall.

Figure 3.2: Dimensions of the heater for proper placement and installation.

Figure 3.3: The heater is suitable for various rooms, including bathrooms due to its IP24 rating.

4. Kullanım Talimatları

The Klarstein Bornholm heater can be operated via its touch control panel or the included remote control.

4.1 Güç Açma/Kapama:

Plug the heater into a suitable power outlet. Press the power button on the control panel or remote control to turn the unit on or off.

4.2 Sıcaklığın Ayarlanması:

Use the '+' and '-' buttons on the control panel or remote to adjust the desired room temperature. The display will show the set temperature. The heater will automatically cycle on and off to maintain this temperature.

4.3 Power Modes (1000W/2000W):

Some models may offer different power settings (e.g., 1000W or 2000W) to optimize energy consumption based on heating needs. Refer to the display or specific button on the remote for mode selection.

4.4 Zamanlayıcı Fonksiyonu:

Activate the timer function to set a specific duration after which the heater will automatically turn off. Consult the manual's detailed section for programming the timer, which may include daily or weekly cycles.

4.5 Child Safety Lock:

To activate or deactivate the child safety lock, press and hold the designated button on the control panel or remote control for a few seconds. This will prevent unauthorized changes to the settings.

5. Bakım

Düzenli bakım, ısıtıcınızın uzun ömürlü ve verimli çalışmasını sağlar.

• Temizlik: Temizlemeden önce ısıtıcının fişini çekin ve tamamen soğumasını bekleyin. Dış yüzeylerini yumuşak, kuru bir bezle silin.amp Bezle silin. Aşındırıcı temizleyiciler, çözücüler veya sert kimyasallar kullanmayın.
• Depolamak: Isıtıcıyı uzun süre saklayacaksanız, temiz ve kuru olduğundan emin olun. Serin ve kuru bir yerde, tercihen orijinal ambalajında ​​saklayın.
• Denetleme: Periodically check the power cord and plug for any signs of damage. If damage is found, do not use the heater and contact customer support.

6. Sorun Giderme

Isıtıcınızla ilgili sorunlarla karşılaşırsanız, aşağıdaki yaygın sorunlara ve çözümlere bakın:

Bu çözümleri denedikten sonra sorun devam ederse, lütfen Klarstein müşteri desteğiyle iletişime geçin.

7. Özellikler

Detailed technical specifications for the Klarstein Bornholm 2000W Electric Convector Heater:

8. avanstages of a Convector Heater

Convector heaters, like the Klarstein Bornholm, offer several benefits compared to other heating types:

Figure 8.1: Comparison of heating types, highlighting the benefits of convector heaters such as air heating, silent operation, rapid heating, and suitability for allergy sufferers.

• Air Heating: Efficiently heats the air in the room, providing uniform warmth.
• Sessiz Çalışma: Operates quietly without disruptive fan noise.
• Hızlı Isıtma: Quickly brings the room to the desired temperature.
• Basit Kurulum: Easy to set up as freestanding or wall-mounted.
• Comfortable Heat: Provides a comfortable warmth that does not dry out the air.
• Suitable for Allergy Sufferers: Does not circulate dust as much as fan heaters.

9. Garanti ve Destek

For warranty information, technical support, or service inquiries, please contact Klarstein customer service. Refer to your purchase documentation for specific warranty terms and contact details.

You can also visit the official Klarstein webEk kaynaklar ve destek bilgileri için siteyi ziyaret edin.
