Osaki OS-4000LS Massage Chair User Manual

1. Giriş

Thank you for choosing the Osaki OS-4000LS Massage Chair. This manual provides essential information for the safe and effective use of your massage chair. The OS-4000LS features 42-inch L-Track rollers for comprehensive massage coverage from head to buttocks, enhanced massage intensity, space-saving recline technology requiring less than 4 inches from a wall, and a 3-step shoulder adjustment with footrest extension to accommodate various body types.

Image: The Osaki OS-4000LS massage chair in a cream finish, showcasing its design and remote control.

2. Güvenlik Bilgileri

Please read all instructions carefully before using the massage chair. Keep this manual for future reference.

• Elektriksel Güvenlik: Ensure the power cord is not damaged and is properly plugged into a grounded outlet. Do not operate the chair with wet hands or in damp ortamlar.
• Kullanıcı Kısıtlamaları: Bu cihaz, fiziksel, duyusal veya zihinsel yetenekleri kısıtlı olan veya deneyim ve bilgi eksikliği bulunan kişiler tarafından, güvenliklerinden sorumlu bir kişi tarafından gözetim veya kullanım talimatı verilmedikçe kullanılmak üzere tasarlanmamıştır. Çocukların cihazla oynamamaları için gözetim altında tutulmaları gerekmektedir.
• Tıbbi Durumlar: Herhangi bir sağlık sorununuz varsa, hamileyseniz, kalp pili kullanıyorsanız veya tıbbi tedavi görüyorsanız, kullanmadan önce bir doktora danışın.
• Doğru Kullanım: Do not stand on the chair or use it for purposes other than massage. Avoid prolonged use in one area to prevent discomfort.
• Çevre: Use the chair on a flat, stable surface. Keep away from heat sources and direct sunlight.

3. Kurulum ve Yerleştirme

The Osaki OS-4000LS massage chair is delivered curbside and may require some assembly. Ensure you have adequate space for installation and operation.

1. Paketin açılması: Carefully remove all packaging materials. Retain packaging for potential future transport.
2. Toplantı: Follow the specific assembly instructions provided in the separate assembly guide. Typically, this involves attaching the footrest and side panels.
3. Atama: Position the chair on a level, stable floor. Due to its space-saving recline technology, the chair requires less than 4 inches of clearance from a wall for full recline.
4. Güç Bağlantısı: Plug the power cord securely into a grounded electrical outlet.

Image: Diagram showing the dimensions of the Osaki OS-4000LS massage chair, indicating a depth of 100 inches, width of 50 inches, and height of 100 inches.

4. Kullanım Talimatları

The OS-4000LS offers various massage programs and adjustments for a personalized experience.

1. Güç Açık: Locate the power button, usually on the side or near the remote control holder, and press it to turn on the chair.
2. Uzaktan kumanda: Use the wired remote control to select massage programs, adjust intensity, recline position, and other settings. Refer to the remote control guide for detailed button functions.
3. L-Track Massage: The 42-inch L-Track system provides massage from your neck down to your glutes. Explore different programs to experience various massage techniques.
4. Omuz Ayarı: Utilize the 3-step shoulder adjustment feature to customize the shoulder massage position for your height.
5. Ayak Dayama Uzantısı: The footrest can be extended to comfortably accommodate users of different heights.
6. Yatırma Fonksiyonu: Use the remote to recline the chair to your desired position. The space-saving design allows for full recline with minimal wall clearance.
7. Kapat: After use, press the power button to turn off the chair and unplug it from the outlet if not in regular use.

Image: A man comfortably seated and relaxing in the Osaki OS-4000LS massage chair, demonstrating its operational use.

5. Bakım

Düzenli bakım, masaj koltuğunuzun uzun ömürlü olmasını ve en iyi performansı göstermesini sağlar.

• Temizlik: Wipe clean the faux leather surfaces with a soft, damp cloth. Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the material.
• Depolamak: If storing the chair for an extended period, unplug it and cover it to protect it from dust.
• Denetleme: Güç kablosunu ve tüm bağlantıları periyodik olarak hasar belirtileri açısından kontrol edin. Herhangi bir hasar tespit edilirse, kullanımı durdurun ve müşteri desteğiyle iletişime geçin.

6. Sorun Giderme

If you encounter issues with your Osaki OS-4000LS massage chair, refer to the following common solutions:

• Sandalye açılmıyor:
  • Güç kablosunun çalışan bir elektrik prizine güvenli bir şekilde takıldığından emin olun.
  • Check if the power switch on the chair is in the 'ON' position.
  • Verify the circuit breaker for the outlet has not tripped.
• Massage function is not working:
  • Confirm the chair is powered on and the remote control is functioning.
  • Ensure no objects are obstructing the massage rollers or footrest.
  • Try restarting the chair by powering it off and on again.
• Çalışma sırasında olağandışı sesler:
  • Minor operational sounds are normal. If noises are loud or unusual, power off the chair immediately.
  • Herhangi bir gevşek parça veya tıkanıklık olup olmadığını kontrol edin.

Bu adımlar sorunu çözmezse lütfen müşteri desteğiyle iletişime geçin.

7. Özellikler

8. Garanti ve İade Koşulları

Lütfen tekrar edinview the following information regarding product returns and guarantees:

• 30 Günlük Para İade Garantisi: A 30-day money-back guarantee is offered, minus the cost of shipping.
• Restocking Fee: A restocking fee of up to 20% of the item's price may apply to returns.
• Hasarlı Ürünler: Items with damages caused by the buyer are not returnable.

For detailed warranty information, please refer to the warranty card included with your product or contact Osaki customer support.

9. Müşteri Desteği

For any questions, technical assistance, or service requests, please contact Osaki customer support. Refer to the contact information provided in your product packaging or on the official Osaki webalan.
