SAMSON MS100 Studio Monitor Stands Instruction Manual

1. Giriş

Satın aldığınız için teşekkür ederizasing the SAMSON MS100 Studio Monitor Stands. These professional-grade stands are designed to provide stable and isolated support for your studio monitors, ensuring optimal audio performance. The MS100 features a telescoping column for height adjustment and an adjustable vise-style speaker bracket to accommodate various monitor sizes. Please read this manual thoroughly to ensure proper setup and safe operation.

2. Güvenlik Bilgileri

Yaralanmayı veya ekipmana gelebilecek zararı önlemek için her zaman aşağıdaki güvenlik önlemlerine uyun:

• Ensure all components are securely fastened before placing monitors on the stands.
• Do not exceed the maximum weight capacity of the stands (consult product specifications or manufacturer for specific limits).
• Place stands on a stable, level surface to prevent tipping.
• Keep children and pets away from the stands, especially during adjustment.
• Avoid placing stands in high-traffic areas where they could be accidentally knocked over.

3. Paket İçeriği

Paketinizin aşağıdaki öğeleri içerdiğini doğrulayın:

• 2 x SAMSON MS100 Studio Monitor Stands (each comprising a base, telescoping column, and speaker bracket)
• Carpet spikes (typically pre-installed or included for optional attachment to the base)
• Assembly hardware (screws, washers, and any necessary tools if provided)
• Kullanım Kılavuzu (bu belge)

4. Montaj ve Kurulum

Follow these steps to assemble and set up your MS100 Studio Monitor Stands:

1. Attach the Column to the Base: Securely fasten the main telescoping column to the heavy base using the provided hardware. Ensure it is tightened firmly to prevent wobbling.
2. Install Carpet Spikes (Optional): If using on carpeted surfaces, ensure the carpet spikes are securely threaded into the bottom of the base. These spikes help to isolate the stand and improve stability.
3. Attach the Speaker Bracket: Mount the adjustable vise-style speaker bracket to the top of the telescoping column. Ensure all screws are tightened.
4. Yüksekliği Ayarlayın: Loosen the locking mechanism on the telescoping column. Adjust the column to the desired height between 30 and 50 inches (76.2 cm - 127 cm). Once the desired height is reached, securely tighten the locking mechanism.
5. Place Studio Monitor: Carefully place your studio monitor onto the speaker bracket. Adjust the vise-style clamps to securely hold the monitor in place without overtightening. Ensure the monitor is centered and stable.

Image description: A fully assembled SAMSON MS100 Studio Monitor Stand with a studio monitor resting on its adjustable bracket. The stand is black with a heavy base, demonstrating its stable design.

5. Kullanım Talimatları

Once assembled, the MS100 stands are ready for use. Position them in your studio or listening environment to achieve optimal sound staging and isolation. Ensure monitors are securely seated on the brackets and the stands are stable before use.

• Monitör Yerleşimi: Place your studio monitors on the adjustable vise-style brackets. Ensure the monitors are balanced and the clamps are tightened just enough to hold them securely without causing damage.
• Yükseklik Ayarı: For optimal listening, the acoustic axis of your monitors should be at ear level when you are in your primary listening position. Adjust the telescoping column as described in Section 4, Step 4, to achieve this.
• Stabilite Kontrolü: Periodically check that all connections are tight and the stands remain stable, especially after moving them or adjusting height.

6. Bakım

The SAMSON MS100 Studio Monitor Stands require minimal maintenance:

• Temizlik: Wipe down the stands with a soft, dry cloth to remove dust. Avoid abrasive cleaners or solvents.
• Denetleme: Tüm cıvata ve bağlantıların sıkılığını düzenli olarak kontrol edin. Gerekirse yeniden sıkın.
• Depolamak: If storing the stands for an extended period, ensure they are clean and dry. They can be disassembled for more compact storage if desired.

7. Sorun Giderme

If you encounter any issues with your MS100 Studio Monitor Stands, refer to the following common solutions:

• Stand Sallantıda:
  • Ensure the column is securely fastened to the base.
  • Verify the height adjustment locking mechanism is fully tightened.
  • Check that the stand is on a level surface. Adjust carpet spikes if applicable.
• Monitor Not Secure:
  • Ensure the vise-style clamps are tightened sufficiently to hold the monitor.
  • Verify your monitor's dimensions are compatible with the bracket.

8. Özellikler

Not: Özellikler önceden haber verilmeksizin değiştirilebilir.

9. Garanti Bilgileri

The SAMSON MS100 Studio Monitor Stands are covered by a 3 yıllık parça ve işçilik garantisi Satın alma tarihinden itibaren geçerlidir. Bu garanti, normal kullanım koşullarında üretim hatalarını ve işçilik kusurlarını kapsar. Yanlış kullanım, kazalar, yetkisiz değişiklikler veya hatalı montajdan kaynaklanan hasarları kapsamaz.

For warranty service, please retain your proof of purchase and contact SAMSON customer support.

10. Müşteri Desteği

If you have any questions, require technical assistance, or need to inquire about warranty service, please contact SAMSON customer support through their official webÜrünü satın aldığınız site veya perakendeci.

SAMSON Official Webalan: www.samsontech.com

Please note that specific contact details may vary by region. Refer to the official weben güncel bilgiler için site.
