1. Giriş
This manual provides comprehensive instructions for the setup, operation, and maintenance of your Blue Wave Martinique Above-Ground Swimming Pool. Designed for durability and ease of use, this pool package includes essential components for a complete backyard aquatic experience. Please read this manual thoroughly before beginning installation or operation to ensure proper assembly, safe use, and longevity of your pool.
2. Güvenlik Bilgileri
Your safety and the safety of others are paramount. Adhere to all safety warnings and instructions. Failure to do so may result in serious injury or property damage.
- Havuz kullanımdayken çocukları ve yüzme bilmeyenleri daima gözetim altında tutun.
- Havuza dalmayın veya atlamayın. Havuzun derinliği dalış için uygun değildir.
- Ensure the pool area is clear of obstructions and hazards.
- Secure the ladder or remove steps when the pool is not in use to prevent unsupervised access by children.
- Tüm elektrikli cihazları havuzdan uzak tutun.
- This product contains small parts which may present a choking hazard for young children.
- UYARI: Bu ürün, Kaliforniya Eyaleti tarafından kansere ve doğum kusurlarına veya diğer üreme zararlarına neden olduğu bilinen kurşun dahil kimyasallara maruz kalmanıza neden olabilir. Daha fazla bilgi için şuraya gidin: www.P65Uyarılar.ca.gov.
3. Paket İçeriği
Verify that all components listed below are present and undamaged before beginning assembly. If any parts are missing or damaged, contact customer support immediately.
- Galvanized Steel Pool Wall
- 7-Inch Top Rails and Uprights
- Overlap Standard-Gauge Liner
- Skimmer and Return System
- Sand Filter System with 1-HP Dual-Speed Pump
- A-Frame Flip-Up Ladder
- Bakım Seti (Naylon Duvar Fırçası, Vinil Astar Vakum Başlığı, Yaprak Toplayıcı, 3 Parçalı 12 Metre Direk, Termometre, 25 Metre Vakum Hortumu)
- Hardware and Fasteners
- Kullanım Kılavuzu
Şekil 3.1: Üzerindeview of the Blue Wave Martinique pool package components, including the main pool structure, sand filter system, A-frame ladder, blue overlap liner, skimmer, and various maintenance tools.
4. Kurulum ve Kurulum
This section outlines the steps for assembling your above-ground pool. It is recommended to have at least two adults for installation.
4.1 Saha Hazırlığı
- Bir Seviye Yeri Seçin: Select a firm, level area in your yard. The ground must be completely flat to ensure the structural integrity of the pool.
- Alanı Temizle: Remove all rocks, roots, sharp objects, and debris from the chosen site.
- Uygun Drenajı Sağlayın: Position the pool away from structures or areas where water runoff could cause damage.
4.2 Havuz Montajı
- Unroll the Pool Wall: Carefully unroll the galvanized steel pool wall in a circular shape, ensuring the skimmer and return openings are positioned correctly.
- Install Bottom Rails and Uprights: Connect the bottom rails and secure the steel uprights around the perimeter of the pool wall.
- Install Top Rails: Attach the 7-inch top rails and resin top caps to the uprights, forming the top perimeter of the pool. These components are designed for strength and corrosion resistance.
- Install Liner: Carefully unfold and position the overlap standard-gauge liner inside the pool structure. Ensure it is centered and smooth out any wrinkles as you begin to fill the pool with water.
- Install Skimmer and Return System: Follow the specific instructions provided with the skimmer and return system to cut the liner and securely install these components.
Şekil 4.1: Ayrıntılı view of the pool's construction, highlighting the 15 ft diameter, 52-inch depth, hot-dip galvanized steel with zinc-aluminum coating, steel uprights for stability, resin top caps for joint protection, and 7-inch top rails for structural reinforcement.
4.3 Ladder Installation
- Merdiveni monte edin: Follow the instructions provided with the A-frame flip-up ladder to assemble it correctly. Ensure all bolts and fasteners are tightened securely.
- Position Ladder: Place the ladder on a solid, level surface outside the pool, with the steps extending into the pool.
- Merdiveni Güvenli Hale Getirin: Ensure the ladder is stable and does not wobble. The ladder is made of durable resin and supports up to 250 lbs.
- Utilize Flip-Up Steps: When the pool is not in use, flip up the steps and secure them to block access, enhancing safety.
Şekil 4.2: Illustration of the pool ladder's safety and comfort features, including durable resin materials, a built-in platform for safe entry and exit, a two-piece barrier for added safety, and lockable flip-up steps to block access when not in use. The ladder dimensions are 81 inches high, 48 inches wide at the base, and 24 inches deep, with a 250-pound weight capacity.
5. Operasyon
This section details how to operate your Blue Wave Martinique pool and its filtration system.
5.1 Havuzun Doldurulması
Once the pool structure and liner are fully installed, begin filling the pool with water. The pool has a water capacity of approximately 5,130 gallons. As the pool fills, continue to smooth out any wrinkles in the liner.
5.2 Filter System Operation
The included Sandman™ sand filter system is crucial for maintaining clean and clear pool water.
- İlk kurulum: Before operating, ensure the filter tank is filled with the appropriate amount of filter sand (110 lbs capacity).
- Hortumların Bağlanması: Connect the hoses from the skimmer and return system to the filter pump and filter tank as per the filter system's specific instructions.
- Güç Açık: Plug in the 1-HP dual-speed pump. The pump delivers a 16,000-gallon turnover rate and a circulation rate of 3,720 gallons per hour.
- Çalışma Süresi: Operate the filter system daily for several hours to ensure proper water circulation and filtration. The exact duration will depend on pool usage and environmental factors.
Şekil 5.1: The Sandman™ Sand Filter System, featuring a 16,000-gallon turnover rate for efficient water circulation, 1.5-inch diameter pipe fittings for secure connections, a 1.0-HP dual-speed pump with a 3,720 gallons per hour circulation rate, and a 110-pound sand capacity for effective dirt and debris trapping.
6. Bakım
Regular maintenance is essential for keeping your pool clean, safe, and extending its lifespan.
6.1 Rutin Temizlik
- Sıyırma: Use the leaf skimmer daily to remove floating debris from the water surface.
- Fırçalama: Use the nylon wall brush to brush the pool walls and floor at least once a week to prevent algae growth and loosen debris.
- Vakumlama: Connect the vinyl liner vacuum head to the 25-ft vacuum hose and the skimmer to vacuum the pool floor as needed.
- Filter Backwashing: Periodically backwash your sand filter as indicated by pressure gauge readings or reduced flow, to clean the filter media. Refer to your filter system manual for detailed instructions.
Şekil 6.1: The Economy Maintenance Kit includes essential tools for pool upkeep: a nylon wall brush, vinyl liner vacuum head, leaf skimmer, a 3-piece 12-foot pole, a thermometer, and a 25-foot vacuum hose.
6.2 Su Kimyası
Regularly test and balance your pool water chemistry using a pool test kit. Maintain appropriate levels for pH, alkalinity, calcium hardness, and sanitizer (e.g., chlorine) to ensure water quality and prevent damage to pool components.
6.3 Kışa Hazırlık
Before freezing temperatures arrive, properly winterize your pool to protect it from damage. This typically involves cleaning the pool, balancing water chemistry, lowering the water level, draining equipment, and covering the pool. Consult a pool professional or specific winterization guides for detailed steps.
7. Sorun Giderme
This section addresses common issues you might encounter with your pool and provides potential solutions.
| Sorun | Olası Neden | Çözüm |
|---|---|---|
| Water Leaking from Pool | Liner puncture or tear; Loose connections at skimmer/return; Damaged pump/filter components. | Inspect liner for damage and patch if necessary. Tighten all hose clamps and connections. Check pump and filter for cracks or loose fittings. |
| Filter Pump Not Operating / Low Flow | No power; Clogged skimmer basket/pump impeller; Low water level; Dirty filter sand. | Check power supply and circuit breaker. Clean skimmer basket and pump impeller. Ensure water level is above skimmer opening. Backwash filter or consider sand replacement. |
| Bulanık Havuz Suyu | Improper water chemistry; Insufficient filtration; Algae growth. | Test and balance water chemistry (pH, alkalinity, sanitizer). Increase filter run time. Backwash filter. Shock treat the pool if algae is present. |
| Merdiven Dengesizliği | Improper assembly; Uneven ground; Loose fasteners. | Re-check ladder assembly instructions and tighten all fasteners. Ensure the ground beneath the ladder is level and firm. |
8. Özellikler
| Özellik | Detay |
|---|---|
| Marka | Mavi Dalga |
| Model Numarası | NB3110 |
| Şekil | Yuvarlak |
| Ürün Boyutları (U x G x Y) | 180" x 180" x 52" (15-Feet Diameter x 52-Inch Deep) |
| Su Kapasitesi | Yaklaşık 5,130 galon |
| Malzeme | Alloy Steel (Galvanized Steel Wall with Zinc-Aluminum Coating) |
| Top Rail Size | 7-İnç |
| Filtre sistemi | Sandman™ Sand Filter with 1-HP Dual-Speed Pump |
| Filter Turnover Rate | 16,000 Galon |
| Pump Circulation Rate | 3,720 Gallons/Hour |
| Sand Capacity (Filter) | 110 pound |
| Merdiven Taşıma Kapasitesi | 250 pound |
| Dahil Bileşenler | Skimmer, Return System, Blue Overlap Liner, Sand Filter & Pump System, A-Frame Ladder, Maintenance Kit |
| Ürün Ağırlığı (Paket) | 1 Pound (Note: This is likely a placeholder or incorrect weight for the entire package) |
| UPC | 672875400140 |
| Menşei ülke | Japonya |
9. Garanti Bilgileri
The Blue Wave Martinique Above-Ground Swimming Pool Package is backed by a 20 yıllık sınırlı garanti. This warranty covers defects in materials and workmanship under normal use and service. Please retain your proof of purchase for warranty claims. For specific terms and conditions, refer to the warranty documentation included with your product or contact Blue Wave customer support.
Şekil 9.1: An image indicating a 15-year limited warranty, though the product description states a 20-year limited warranty. Please refer to the official warranty documentation for the most accurate and up-to-date warranty period.
10. Müşteri Desteği
If you have any questions, require assistance with assembly, or need to report missing or damaged parts, please contact Blue Wave customer support. Have your model number (NB3110) and proof of purchase ready when contacting support.
For the most current contact information, please visit the official Blue Wave website or refer to the packaging materials.
