1. Giriş

This manual provides essential information for the safe and efficient use of your new Faber Hob Magiclift HT753 BR CI AI 75 cm 3 Burner. Please read these instructions carefully before installation, operation, or maintenance. Keep this manual for future reference.

Figure 1: Faber Hob Magiclift HT753 BR CI AI 75 cm 3 Burner, showcasing its sleek black glass surface and three brass burners.

2. Güvenlik Bilgileri

UYARI: Yanlış kurulum, ayarlama, değişiklik, servis veya bakım maddi hasara, yaralanmaya veya ölüme neden olabilir. Bu ekipmanı kurmadan veya bakımını yapmadan önce kurulum, çalıştırma ve bakım talimatlarını baştan sona okuyun.

• Mutfak alanında yeterli havalandırmanın sağlanmasına özen gösterin.
• Yanıcı maddeleri ocağın yakınında saklamayın.
• Always use appropriate cookware for gas cooking.
• Çalışma sırasında çocukları cihazdan uzak tutun.
• In case of a gas leak, immediately turn off the gas supply, open windows, and do not operate any electrical switches or appliances. Contact a qualified technician.
• This appliance is equipped with a Flame Failure Device (FFD) which automatically cuts off the gas supply if the flame extinguishes.

3. Ürün Bittiview

The Faber Hob Magiclift HT753 BR CI AI features a toughened 8mm matt finish black glass surface, three high-efficiency brass burners, and premium control knobs. Its unique liftable burner design enhances convenience for cleaning.

Temel Özellikler:

• Liftable Burners: Kolay temizlik ve bakım için.
• Auto Ignition: In-built battery-operated ignition for quick start-up.
• Flame Failure Device (FFD): Enhances safety by cutting off gas supply if the flame goes out.
• Cast Iron Pan Support: Durable and stable support for cookware.
• Premium Knobs: Ergonomic design for precise flame control.
• Toughened Black Glass: 8mm thick, matt finish for durability and aesthetics.

Bileşenler:

1. Toughened Glass Surface
2. Brass Burners (2 x 3.0 kW, 1 x 2.5 kW)
3. Dökme Demir Tava Destekleri
4. Kontrol Düğmeleri
5. Ignition System (underneath knobs)
6. Flame Failure Devices (integrated into burners)

Figure 2: Illustration of the liftable burner mechanism, showing how the burner can be raised for access to the hob surface.

Figure 3: Close-up of a brass burner demonstrating its dual flame functionality, offering both a lower single flame (2.5 kW) and a full burner (3.0 kW) for cooking flexibility.

Şekil 4: Ayrıntılı view of the Flame Failure Device (FFD) integrated into the burner, a safety feature that automatically cuts off gas supply.

Figure 5: Layout of the three brass burners, indicating the power distribution: two 3.0 kW burners and one 2.5 kW burner.

4. Kurulum ve Yükleme

The Faber Hob Magiclift HT753 BR CI AI is designed for drop-in installation. Professional installation by a qualified technician is highly recommended to ensure safety and proper functioning.

Kurulum Adımları:

1. Tezgahı Hazırlayın: Ensure the countertop cutout dimensions match the hob's requirements. The hob dimensions are 38D x 75W x 13.5H Centimeters.
2. Gaz Bağlantısı: Connect the hob to a suitable gas supply line using approved fittings and flexible hoses. Ensure all connections are leak-free.
3. Electrical Connection (for Ignition): Install the battery for the auto-ignition system as per the instructions provided in the packaging.
4. Position the Hob: Carefully lower the hob into the countertop cutout, ensuring it sits flush and is securely supported.
5. Test İşlemi: After installation, test all burners for proper ignition and flame stability. Check for any gas leaks.

Dahil Bileşenler: 1 Built-In Gas Stove, 1 Warranty Card, 1 User Manual.

5. Kullanım Talimatları

Brülörü Ateşlemek:

1. Place your cookware centrally on the cast iron pan support over the desired burner.
2. Push down and turn the corresponding control knob counter-clockwise to the maximum flame position.
3. The auto-ignition system will click, and the burner will ignite. Hold the knob down for a few seconds to allow the Flame Failure Device (FFD) to activate.
4. Once the flame is stable, release the knob. If the flame extinguishes, repeat the process.
5. Adjust the flame intensity by rotating the knob between the maximum and minimum flame settings.

Using Dual Functionality Burners:

The brass burners offer dual flame functionality. When igniting, the full burner ignites with 3.0 kW power. For a lower, more flexible flame (2.5 kW), adjust the knob to the appropriate setting as indicated by the knob markings.

Figure 6: Demonstrates the 'Lift & Lock' feature, allowing burners to be securely raised for convenient access during cooking or cleaning.

6. Bakım ve Temizlik

Düzenli temizlik ve bakım, ocağınızın uzun ömürlü olmasını ve en iyi performansı göstermesini sağlayacaktır.

Genel Temizlik:

• Always ensure the hob is cool and the gas supply is turned off before cleaning.
• Cam Yüzey: Use a soft cloth and a mild, non-abrasive cleaner specifically designed for glass surfaces. Avoid harsh chemicals or abrasive pads that can scratch the glass.
• Dökme Demir Tencere Destekleri: These can be removed and washed with warm soapy water. Dry thoroughly before placing them back on the hob.
• Brülörler: The liftable burners allow for easy access. Remove the burner caps and crowns. Clean them with warm soapy water and a soft brush. Ensure all burner parts are completely dry before reassembling. Clogged burner holes can affect flame quality.

Figure 7: The liftable burners simplify the cleaning process, allowing easy access to the hob's black glass surface.

7. Sorun Giderme

Herhangi bir sorunla karşılaşırsanız, aşağıdaki sık karşılaşılan sorunlar ve çözümlerine bakın. Sorun devam ederse, müşteri desteğiyle iletişime geçin.

8. Özellikler

9. Garanti ve Destek

Garanti Bilgileri:

• Kapsamlı Garanti: 2 Yıl
• Genişletilmiş Garanti: 5 Years on Glass, Burners & Valves

Garanti talepleriniz için lütfen satın alma fişinizi ve garanti kartınızı saklayın.

Müşteri Desteği:

For service, technical assistance, or warranty inquiries, please contact Faber customer support:

Ücretsiz Numara: 1800-209-3484

Manufacturer: Franke Faber India Pvt Ltd

Address: 1086/1/2, SANASWADI, TAL - SHIRUR, PUNE - 412208, MAHARASHTRA, INDIA
