1. Giriş
This manual provides essential instructions for the safe and effective use of your Paddie Portable Tattoo Chair / Mobile Massage Table, Model BU0115. This versatile unit is designed for professional applications such as massages, tattoos, eyelash extensions, microblading, waxing, and dental treatments. Please read this manual thoroughly before assembly and operation to ensure proper function and longevity of your product.
2. Güvenlik Bilgileri
Always read and follow the assembly instructions carefully. Keep sharp objects away from the chair when not in use. Use proper lifting techniques to prevent injury when moving the chair. Do not exceed the weight limit of 150kg (330lbs). Keep the chair away from heat sources to prevent damage to the material.
3. Paket İçeriği
Montaj işlemine başlamadan önce tüm bileşenlerin mevcut olduğundan emin olun:
- 1 x Paddie Portable Tattoo Chair
- 1 x Saklama Çantası
- 1 x Kullanım Kılavuzu (bu belge)
4. Kurulum Talimatları
The Paddie Portable Tattoo Chair requires some assembly upon first use. While designed to be foldable for transport, complete folding and unfolding involves detaching and reattaching support rods. Basic tools (a Philips screwdriver and small wrench) are required for this process.
4.1 Sandalyenin Açılması
- Carefully remove the chair from its storage bag.
- Unfold the main sections of the chair.
- Locate the support rods for the backrest and footrest. These rods connect the adjustable sections to the main frame.
- Securely attach the support rods using the provided bolts and nuts. Ensure all connections are tight before use.
- Attach the detachable headrest and armrests as desired.
Figure 4.1: Folding and Unfolding Diagram. Reverse these steps for initial setup.
4.2 Detachable Components
The headrest and armrests are designed for easy removal and attachment, allowing for customization based on the specific treatment or client needs.
Figure 4.2: Detachable Headrest and Anti-Slip Pads.
5. Kullanım Talimatları
The Paddie Portable Tattoo Chair offers adjustable sections to accommodate various client positions.
5.1 Adjusting Backrest and Footrest
The backrest can be adjusted up to an 85-degree angle, and the footrest can be adjusted down to an 85-degree angle. To adjust, loosen the locking mechanism on the support rods, position the section to the desired angle, and then securely tighten the locking mechanism. Ensure the client is safely positioned before making adjustments.
Figure 5.1: Backrest and Footrest Adjustment Range.
6. Bakım
Proper maintenance ensures the longevity and hygienic condition of your Paddie Portable Tattoo Chair.
6.1 Temizlik
The chair is made with wear-resistant PU leather. To clean, wipe the surface with a dry cloth. For more thorough cleaning, a damp cloth can be used to wipe away dust and dirt. Avoid harsh chemicals or abrasive cleaners that may damage the PU leather.
6.2 Depolama
When not in use, the chair can be folded for compact storage. To fold, you must unbolt the support rods for the back and legs. Once folded, place the chair in the provided storage bag to protect it from dust and damage. Store in a dry, cool place.
Figure 6.1: Folded Chair with Storage Bag.
Figure 6.2: Folded Chair in Car Trunk for Transport.
7. Sorun Giderme
Bu bölüm, sıkça karşılaşılan endişeleri ele almakta ve çözümler sunmaktadır.
7.1 Chair is Difficult to Fold/Unfold
The chair's design requires the support rods for the backrest and footrest to be unbolted and removed before folding. This is a necessary step for compact storage. Ensure you have the appropriate tools (small wrench and Philips screwdriver) readily available for this process.
7.2 Chair Feels Heavy for Transport
The chair weighs approximately 59 lbs (27 kg) due to its heavy-duty steel frame, which contributes to its stability and durability. While foldable, its weight means it may require effort to transport. Use proper lifting techniques or assistance when moving the chair.
7.3 No Locking Mechanism When Folded
The chair does not feature an automatic locking mechanism when folded. Exercise caution when handling the folded chair to prevent sections from swinging open. The storage bag helps contain the folded unit.
7.4 Chair Height is Too Tall
The chair has a fixed height. If the working height is too high for certain procedures or for the artist, consider using an adjustable-height stool for the practitioner to achieve a comfortable working position.
8. Özellikler
| Özellik | Detay |
|---|---|
| Model Numarası | BU0115 |
| Renk | Beyaz |
| Malzeme | High-Quality PU Leather, Metal Frame |
| Açılmış Haldeki Boyutlar (Uzunluk x Genişlik x Yükseklik) | 72.0" x 22.8" x 27.0" |
| Katlanmış Boyutlar (U x G x Y) | 27.8" x 24.0" x 29.8" |
| Ürün Ağırlığı | 59 lbs (27 kg) |
| Ağırlık Kapasitesi | 330 lbs'ye (150 kg) kadar |
| Sırt Ayarı | 0-85 derece |
| Ayaklık Ayarı | 0-85 derece |
| Dahil Bileşenler | Tattoo Chair, Storage Bag, Instruction Manual |
Figure 8.1: Product Dimensions and Key Specifications.
9. Garanti ve Destek
For warranty information or technical support, please refer to the documentation included with your purchase or contact Paddie customer service directly. Contact details can typically be found on the manufacturer's official websitede veya satın alma fişinizde yer almaktadır.
